Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
31
14SL30
21SL40, 21SL70
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual; electrical components having such features
are identified by å and shaded areas in the Replacement Parts Lists
and Schematic Diagrams. The use of a substitute replacement part
which dose no have the same safety characteristic as the factory
recommended replacement parts shown in this service manual may
create shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
★MARK : SPARE PARTS-DELIVERY SECTION
'MARK : X- RAY RELATED PARTS
Ref. No. Part No. ★ Description Code
PICTURE TUBE
14SL30
çå V101 VB370BVBK1S-S R CRT (DY601:H0140PE, H0150PE, BZ
or H0160PE, H0140PEN1)
VB34JFQ90X/*S CRT (DY601:H0140PE, H0150PE,
or H0160PE, H0140PEN1)
VB34KPU02X/*S CRT (DY601:H0149PEN1,
or H0164PEN1)
VB34JLL40X/*S CRT (DY601:H0163PE)
or
VB37GDA86X/1E CRT (DY601:H0149PE, H0164PE)
çå DY601 RCiLH0140PEZZ R DY (CRT:CPJ370BVBK1S BC
or or A34JFQ90X)
RCiLH01050PEZZ DY (CRT:CPJ370BVBK1S
or or A34JFQ90X)
RCiLH0160PEZZ DY (CRT:CPJ370BVBK1S
or or A34JFQ90X)
RCiLH0140PEN1 DY (CRT:CPJ370BVBK1S
or or A34JFQ90X)
RCiLH0149PEZZ DY (CRT:37GD86X)
or
RCiLH0149PEN1 DY (CRT:A34KPU02XX)
or
RCiLH0163PEZZ DY (CRT:A34JLL40X)
or
RCiLH0164PEZZ DY (CRT:37GDA86X)
or
RCiLH0164PEN1 DY (CRT:A34KPU02XX)
å L702 RCiLG0106GJZZ X Degaussing Coil
or
RCiLG0037PEZZ
PMAGF3041CEZZ J Magnet AG
QEARC1433PEZZ R Grounding Part AF
TUNER
NOTE : THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
å TU51 VTU115B8035AH X Tuner AH
or
VTU115B8025AM
INTEGRATED CIRCUITS
IC101 VHiKA78S05P-1 J KA78S05P AD
çå IC201 RH-iX3253CEZZ J TA1268AN AV
å IC501 VHiTA8403K/-1 J TA8403K AL
å IC701 VHiSTRF6654-1 J STRF6654 AX
å IC702 RH-FX0008GEZZ J PC123FY8 AE
å IC703 VHiMiP0254/-1 X MIP0254
å IC704 RH-FX0008GEZZ J PC123FY8 AE
å IC751 VHiKA7809Pi-1 M KA7809PI AE
or
VHiTA7809S/-1
å IC752 VHiKA7809Pi-1 M KA7809PI AE
or
VHiTA7809S/-1
å IC753 VHiSE115N//-1 J SE115N AF
IC2001 RH-iX3256CEZZ J TMPA8701CMF142 AX
IC2040 VHiPST994C/-1 J PST994C AD
IC2101 VHiM24C01B/-1 J M24C01-BN6 AF
or
RH-iX2447CEN1
IC5301 VHiAN5276//-1 J AN5276 AR
TRANSISTORS
You can substitute "VC2SC2462-C-1" for "VS2SD601AR/-1".
Q201 VS2SC2735//1E J 2SC2735 AC
Q401 VS2SD601AR/-1 J 2SD601AR AC
Q402 VS2SB709AR/-1 J 2SB709AR AC
Q403 VS2SD601AR/-1 J 2SD601AR AC
Q404 VS2SB709AR/-1 J 2SB709AR AC
Q451 VS2SB709AR/-1 J 2SB709AR AC
Q601 VS2SC2482//-1 J 2SC2482 AD
or
VS2SC2610/-1E
å Q602 VS2SD2586//1E J 2SD2586 AM
Q752 VS2SC3198-G-1 J 2SC3198(G) AA
21SL40, 21SL70
çå V101 VB51KRE89X/3E X Picture Tube
çå DY601 RCiLH0101GJZZ X Deflection Yoke
å L702 RCiLG0025PEZZ R Degaussing Coil AW
PMAGF3003CEZZ J Magnet AK
QEARC2119PEZZ R Grounding Part AG
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
14SL30
PWB-A DUNTK9882WEV0 – Main Unit —
PWB-B DUNTK9432WEV2 – CRT Unit —
PWB-C DUNTK9883WEV0 – Front AV Unit —
21SL40
PWB-A DUNTK9882WEV1 – Main Unit —
PWB-B DUNTK9432WEV6 – CRT Unit —
PWB-C DUNTK9883WEV1 – Front AV Unit —
21SL70
PWB-A DUNTK9882WEV2 – Main Unit —
PWB-B DUNTK9432WEV6 – CRT Unit —
PWB-C DUNTK9883WEV2 – Front AV Unit —
PWB-A: DUNTK9882WEV1 (21SL40)
MAIN UNIT
COMBINATION
TU51 VTU115B8035AH VTU115B8025AM
C54 VCEA0A1HW475M VCEA0A1HW225M
C55 VCEA0A1CW477M VCEAGA1CW108M
D53 RH-EX0611GEZZ Not Used
R51 VRS-VV3AB331J VRS-VV3DB151J
R52 VRS-VV3DB470J VRD-RA2BE1R0J
R57 VRS-CY1JF392J VRS-CY1JF103J
