Ref. No.Part No.★DescriptionCodeRef. No.Part No.★DescriptionCode
28
TUNER
NOTE:THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDETLY
åTU51VTUVTST5UF670 MTuner
(20MU11)
INTEGRATED CIRCUITS
IC101VHIKA78L05B-1+ KA78L05B AD
1
çåIC201RH-iX3253CEZZJTA1268AN AV
IC351VHiTDA7233/-1JTDA7233 AF
å IC501 VHiTA8403K/-1 J TA8403K AL
çåIC701VHiSTR301301EJSTR30130AP
åIC751VHiKA7809Pi-1RKA7809PIAD
åIC761VHiKA7812Pi-1 RKA7812PI AD
IC2001RH-iX3256CEZZJTMPA8701CMF142AX
IC2040VHiPST994C/-1JPST994CAD
IC2101VHiM24C01B/-1JM24C01-BN6AF
TRANSISTORS
Q201VS2SC2735//1EJ2SC2735AC
Q351VS2SD601AR/-1J2SD601ARAC
Q401VS2SD601AR/-1J2SD601ARAC
Q403VS2SD601AR/-1J2SD601ARAC
Q404VS2SB709AR/-1J2SB709ARAC
Q451VS2SB709AR/-1J2SB709ARAC
Q501VS2SD601AR/-1J2SD601ARAC
Q601VS2SC2655Y/-1J2SC2655(Y)AE
åQ602VS2SD2586//1EJ2SD2586AM
Q603VS2SC945AQ/-1J2SC945A(Q)AB
Q752VS2SC945AQ/-1J2SC945A(Q)AB
Q753 VS2SA1013//1E J 2SA1013 AD
Q2001 VS2SD601AR/-1 J 2SD601AR AC
Q2002 VS2SD601AR/-1 J 2SD601AR AC
Q2060 VS2SD601AR/-1 J 2SD601AR AC
DIODES
D51RH-EX0611GEZZJZener Diode, 5.1VAA
D52 RH-EX0676GEZZ J Zener Diode, 32V AA
D53 RH-EX0611GEZZ J Zener Diode, 5.1V AA
D401 VHD1SS119//-1 J Diode AB
D402 RH-EX0092CEZZ J Zener Diode, 3.9V AB
D454 RH-EX0103CEZZ J Zener Diode, 5.6V AB
D455 VHD1SS119//-1 J Diode AB
D501 RH-DX0441CEZZ J Diode AC
PWB-A : DUNTK9532WEX0 (20MU11)
MAIN UNIT
å D502 RH-DX0131CEZZ J Diode AC
D601 RH-DX0441CEZZ J Diode AC
D631RH-EX0630GEZZJZener Diode, 9.1VAA
D641 RH-EX0630GEZZ J Zener Diode, 9.1V AA
çå D651 RH-DX0131CEZZ J Diode AC
çå D652 VHD1SS119//-1 J Diode AB
çå D653 RH-EX0091CEZZ J Zener Diode, 22V AB
å D661 RH-DX0444CEZZ J Diode AH
å D701 RH-DX0154CEZZ J Diode AC
å D702 RH-DX0154CEZZ J Diode AC
å D703 RH-DX0154CEZZ J Diode AC
å D704 RH-DX0154CEZZ J Diode AC
D753 VHD1SS119//-1 J Diode AB
D754 VHD1SS119//-1 J Diode AB
D755 RH-DX0441CEZZ J Diode AC
å D756 RH-DX0441CEZZ J Diode AC
D757 VHD1SS119//-1 J Diode AB
D758 RH-DX0131CEZZ J Diode AC
å D760 RH-DX0441CEZZ J Diode AC
å D761 RH-DX0441CEZZ J Diode AC
å D762 RH-DX0441CEZZ J Diode AC
D763 VHD1SS119//-1 J Diode AB
D2001 VHD1SS119//-1 J Diode AB
PACKAGED CIRCUITS
PR701 RMPTP0026CEZZ J Packaged Circuit AF
X801 RCRSB0205CEZZ J Crystal AF
FILTERS
CF301 RFiLC0403CEZZ J Ceramic Filter AE
CF401 RFiLC0013CEZZ J Ceramic Filter AE
CF631 RFiLA0034CEZZ J Ceramic Filter AD
CF2040 RFiLC0121GEZZ J Ceramic Filter AD
SF201 RFiLC0405CEZZ J SAW Filter AH
COILS
L201 VP-XF1R2K0000 J Peaking 1.2µH AB
L202 RCiLi0612CEZZ J VCO Coil AE
L301 VP-XF8R2K0000 J Peaking 8.2µH AB
L302 RCiLi0613CEZZ J IF Coil AE
or
L401 VP-XF120K0000 J Peaking 12µH AB
L402 VP-XF100K0000 J Peaking 10µH AB
L406 VP-XF680K0000 J Peaking 68µH AB
L408 VP-XF100K0000 J Peaking 10µH AB
20MU11
D603 RH-DX0441CEZZ J Diode AC
