21S-FX10L
5 – 11
CHECKING FUNCTION OPERATION (VIDEO & AUDIO) (3)
NO ADJUSTMENT POIN
ADJUSTMENT CONDITION / PROCEDUR
WAVEFORM OR REMARK
15 M.P-IN CHECKING (1) Turn up the volume control to maximum, make sure
the sound is heard from speakers *For model with MP In feature
(2) Make sure M.P IN feature is set to O
N
(
3) Plug in stereo c
able in M.P IN terminal
(4)
'MP IN' OSD will appear at bottom right corner TV screen, RF channel sound will be switched to
M.P IN sound.
(5) Check the sound is normal
16 NOISE MUTE (1) Receive mono-tone signal.
CHECKING (2) Turn up the volume contr
ol to ma
ximum, make sur
e the sound is
heard from the speakers. Then put the unit in no signal state.
(
3) Check the sound mute is ef
fective.
(4) Finally turn sound level of CTV to minimum.
17 OSD LANGUAGE (1) Check OSD LANGUAGE qua
ntity and type for respective model.
QUANTITY CHECK
MODEL QUANTITY ENGLISH SPANISH
2
1S-FX10L
2
OO
18 MTS CHECKING (1) Receive stereo channel.
(2) Press R/C "MTS" button, and the sound will change from STEREO to SAP to MONO.
(3) Check the sound to make sure it is working accordingly.
19 CLOSED CAPTION
(1) Receive closed caption channel.
CHECKING (2) Press R/C "CC" button, and the it w
ill change from OFF to CC1 to CC2 to TEXT1 to TEXT2.
(3) Check the closed caption to m
a
ke sure it is working accor
dingly.
SHOCK TEST CHECKING.
NO
ADJUSTMENT POINT
ADJUSTMENT CONDITION / PROCEDURE WAVEFORM OR OTHERS
1 SHOCK TEST (1) Hit at the top of TV set for two time.
(2) Chec
kTV
set n
ot damage and TV operation operate correctly.
To Next Page
