Sharp 21S-FX10L User Manual

21S-FX10L
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
L203 QJUM-0001AJFWY R Jumper wire
L204 VP-XF2R2K0000Y AB R Peaking 2.2μH
L602 RCILP0223CEZZ+ AD R Coil
L603 RCILZ1005CEZZ AD R Coil
L605 RCILZA095WJZZ
L701 RCILFA187WJZZ AD R Coil
L801 VP-DF100K0000Y AB R Peaking 10μH
L802 VP-CF100K0000Y AB R Peaking 10μH
L803 VP-CF220K0000Y AB R Peaking 22μH
L804 QJUM-0001AJFWY R Jumper wire
L805 QJUM-0001AJFWY R Jumper wire
L807 QJUM-0001AJFWY R Jumper wire
L808 VP-CF100K0000Y AB R Peaking 10μH
L3001 QJUM-0001AJFWY R Coil
SF201 RFILCA055WJQZS R Coil
T602 RTRNFA143WJZZ R H-Volt Transformer
T603 RTRNZA058WJZZ AD R Transformer
T702 RTRNWA305WJZZ R Transformer
C202 VCEA0A1AW108M+ AC R 1000 10V Electrolytic
C203 VCKYCY1HF103ZY AA R 0.01 50V Ceramic
C204 VCEA0A1HW105M+ AB R 1 50V Electrolytic
C206 VCEA0A1HW106M+ AB R 10 50V Electrolytic
C207 VCKYCY1HF103ZY AA R 0.01 50V Ceramic
C208 VCKYCY1HF103ZY AA R 0.01 50V Ceramic
C209 VCKYCY1HF103ZY AA R 0.01 50V Ceramic
C210 VCKYCY1HF103ZY AA R 0.01 50V Ceramic
C211 VCCCCY1HH390JY AA R 39p 50V Ceramic
C212 VCCCCY1HH390JY AA R 39p 50V Ceramic
C301 VCEA0A1EW476M+ AB R 47 25V Electrolytic
C302 VCEA0A1HW224M+ AB R 0.22 50V Electrolytic
C303 VCKYCY1HB102KY AA R
1 50V Ceramic
C304 VCEA0A1HW224M+ AB R 0.22 50V Electrolytic
C305 VCKYCY1HB102KY AA R 1 50V Ceramic
C306 VCEA0A1CW336M+ AC R 33 16V Electrolytic
C308 VCEA0A1EW477M+ AD R 470 25V Electrolytic
C309 VCFYFA1HA474J+ AE R 0.47 50V Mylar
C310 VCFYFA1HA474J+ AE R 0.47 50V Mylar
C314 VCEA0A1HW475M+ AB R 4.7 50V Electrolytic
C370 VCEA0A1CW106M+ AC R 10 16V Electrolytic
C371 VCE9GA1HW225M+ AB R 2.2 50V Electrolytic
C372 VCE9GA1HW225M+ AB R 2.2 50V Electrolytic
C390 VCEA0A1CW106M+ AC R 10 16V Electrolytic
C391 VCKYPA2HB102K+ AA R 1000p 500V Ceramic
C393 VCEA0A1EW228M+ AD R 2200 25V Electrolytic
C394 VCE9GA1HW225M+ AB R 2.2 50V Electrolytic
C395 VCEA0A1HW225M+ AB R 2.2 50V Electrolytic
C451 VCEA0A1CW477M+ AC R 470 16V Electrolytic
C501 VCFYFA1HA104J+ AE R 0.10 50V Mylar
C505 VCEA0A1HW107M+ AB R 100 50V Electrolytic
C508 VCFYAA2AA224J+ AD R 0.22 100V Mylar
C509 VCKYPA1HB103K+ AB R 10p 50V Ceramic
C511 VCEA0A1HW477M+ AB R 470 50V Electrolytic
C513 RC-EZA332WJZZ+ AD R Capacitor
C514 VCFYSA1JB473J+ R Capacitor
C515 VCEACA1HC335J+ AC R 3.3 50V Electrolytic
C601 VCQYTA1HM563J+ AB R 0.56 50V Mylar
C602 VCEA0A1HW475M+ AB R 4.7 50V Electrolytic
C604 VCEA0A2EW336M+ AD R 33 250V Electrolytic
C608 VCQYTA2AA103K+ R 0.1 100V Mylar
C610 VCEA0A1EW226M+ AB R 22 25V Electrolytic
C613 RC-FZA178WJZZ R
C615 RC-FZ0357CEN1 R
C617 VCFPVC3ZA163H AD R 16 1.8KV Metalized Polypro Film
C618 VCQPPC2JB473J R
C619 RC-KZ0033CEZZ+ AC R 0.01 250V Ceramic
C635
VCFPKH2ED394J R
C650 VCKYPA2HB101K+ AB R 100p 500V Ceramic
C670 VCEA0A1HW476M+ AB R 47 50V Electrolytic
C671 VCKYPA1HB102K+ AA R 1 50V Ceramic
C672 VCKYPA1HB103K+ AB R 10p 50V Ceramic
C701 RC-FZ029SCEZZ AD R 220 275V Metalized Plastic Film
C702 RC-KZ0029CEZZ+ AC R 0.01 250V Ceramic
C703 RC-KZ0029CEZZ+ AC R 0.01 250V Ceramic
C704 RC-KZ0029CEZZ+ AC R 0.01 250V Ceramic
C705 RC-EZA229WJZZ AM R 220 400V Electrolytic
C709 VCEA0A1HW104M+ AB R 50V Mylar
C710 VCQYTA1HM103J+ AB R 50V Mylar
C711 VCKYPA1HB332K+ AB R 3300p 50V Ceramic
C719 VCEA0A1VW226M+ AB R 22 50V Electrolytic
C743 VCKYPH3DB561K AC R 560p 2KV Ceramic
C744 VCFYSA1HB105J+ R Capacitor
C750 VCKYPA2HB102K+ AA R 1000p 500V Ceramic
C751 RC-KZ0102GEZZ AC R 2kV Ceramic
C752 VCKYPH3DB561K AC R 560p 2KV Ceramic
C753 RC-EZA235WJZZ AD R 160V Electrolytic
[3] MAIN UNIT
