21S-FX10L
4 – 2
Adjustment Mode Items
Data Service Mode Function Range Default Data
V01 SUB-CON CONTRAST 0~127 127
V02 SUB-TINT TINT 0~127 64
V03 SUB-COL COLOR 0~127 64
V04 SUB-BRI BRIGHT 0~255 128
V05 SUB-SHP-PRE VIDEO-TONE(PRE) 0~63 41
V06 SUB-SHP-OVER VIDEO-TONE(OVER) 0~63 41
V07 V-SHIFT V-SHIFT 0~7 4
V08 H-SHIFT H-PHASE 0~31 16
V09 RF-AGC RF-DELAY 0~127 127
V10 V-SIZE V-SIZE 0~63 32
V11 V-SHIFT50 V-SHIFT(OFFSET) -7~+7 0
V12 H-SHIFT50 H-PHASE(OFFSET) -15~+15 0
V13 V-SIZE50 V-SIZE(OFFSET) -31~+31 0
V14 VIF-VCO VIF-VCO 0~63 32
V15 R-CUT R-CUTOFF 0~255 127
V16 G-CUT G-CUTOFF 0~255 127
V17 B-CUT B-CUTOFF 0~255 127
V18 R-DRI R-DRIVE 0~127 64
V19 B-DRI B-DRIVE 0~127 64
V20 SUB-COLOR-YUV COLOR 0~127 64
V21 SUB-TINT-YUV BASEBAND-TINT 0~127 64
V22 CC-POS CC-POS 0~255 32
V23 SCREEN CUT OFF CUT OFF 0~2 0
V24 SUB-VOL A-ATT
0~127 (O20=0)
0~255 (O20=1)
127
255
V25 H-VCO H-VCO 0~7 4
V26 S-TRAP S-TRAP ADJ 0~127 64
V27 VS-CORRECT VS-CORRECTION 0~63 36
V28 VS-CORRECT50 VS-CORRECTION -13~+13 0
V29 V LINEARITY V-LINEARITY 0~63 35
V30 V LINEARITY50 V-LINEARITY -13~+13 0
V31 PARABOLA E/W PARABOLA 0~63 32
V32 PARABOLA50 E/W PARABOLA -13~+13 0
V33 TRAPEZIUM E/W TRAPEZIUM 0~63 32
V34 TRAPEZIUM50 E/W TRAPEZIUM -13~+13 0
V35 H-SIZE E/W H-SIZE 0~63 32
V36 H-SIZE50 E/W H-SIZE -13~+13 0
V37 UPPER CORNER E/W UPPER CORNER 0~63 32
V38 UPPER CORNER50 E/W UPPER CORNER -13~+13 0
V39 LOWER CORNER E/W LOWER CORNER 0~63 32
V40 LOWER CORNER50 E/W LOWER CORNER -13~+13 0
V41 ANGLE ADJ ANGLE ADJ 0~63 31
V42 ANGLE ADJ50 ANGLE ADJ -13~+13 0
V43 BOW ADJ BOW ADJ 0~63 31
V44 BOW ADJ50 BOW ADJ -13~+13 0
V45 S-TRAP ADJ START S-TRAP ADJ 0~127 25
V46 S-TRAP STOP S-TRAP ADJ 0~127 95
M01 MTS-ATT DIRECT OUT LEVEL ADJ 0~15 10
㩷㩷㩷㩷Note 䋱䋩 V23 = "1" … HORIZONTAL MODE
V23 = "2" … Y-MUTE MODE
㩷㩷㩷㩷Note 䋲䋩 V24䋺These registers are set to maximum value.
