Sharp 21V-FW100S User Manual

21V-FW100S
7
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
R1045 VRS-CY1JF104JY AA R 100K 1/16W Metal Oxide
R1046 VRS-CY1JF472JY AA R 4.7K 1/16W Metal Oxide
R1056 VRS-CY1JF332JY AA R 3.3K 1/16W Metal Oxide
R1074 VRS-CY1JF332JY AA R 3.3K 1/16W Metal Oxide
R1087 VRS-CY1JF000JY AA R 0 1/16W Metal Oxide
R1092 VRS-CY1JF472JY AA R 4.7K 1/16W Metal Oxide
R1382 VRS-CY1JF332JY AA R 3.3K 1/16W Metal Oxide
R1383 VRS-CY1JF103JY AA R 10K 1/16W Metal Oxide
R1384 VRS-CY1JF332JY AA R 3.3K 1/16W Metal Oxide
R1401 VRS-CY1JF101JY AA R 100 1/16W Metal Oxide
R1402 VRD-RA2BE101JY AA R 100 1/8W Carbon
R1403 VRS-CY1JF101JY AA R 100 1/16W Metal Oxide
R1431 VRS-CY1JF101JY AA R 100 1/16W Metal Oxide
R1432 VRS-CY1JF750JY AA R 75 1/16W Metal Oxide
R1801 VRS-CY1JF222JY AA R 2.2K 1/16W Metal Oxide
R1802 VRS-CY1JF124JY AA R 120K 1/16W Metal Oxide
R1803 VRS-CY1JF475JY AA R 4.7M 1/16W Metal Oxide
R1894 VRS-CY1JF473JY AA R 47K 1/16W Metal Oxide
R1895 VRS-CY1JF473JY AA R 47K 1/16W Metal Oxide
R1896 VRS-CY1JF473JY AA R 47K 1/16W Metal Oxide
R3001 VRD-RA2BE221JY AA R 220 1/8W Carbon
R3002 VRD-RA2BE221JY AA R 220 1/8W Carbon
R3003 VRS-CY1JF105JY AA R 1M 1/16W Metal Oxide
R3004 VRS-CY1JF104JY AA R 100K 1/16W Metal Oxide
R3005 VRS-CY1JF623JY AA R 62K 1/16W Metal Oxide
R3007 VRS-CY1JF332JY AA R 3.3K 1/16W Metal Oxide
R3008 VRS-CY1JF302JY AA R 3K 1/16W Metal Oxide
R3010 VRS-CY1JF392JY AA R 3.9K 1/16W Metal Oxide
R3011 VRS-CY1JF102JY AA R 1K 1/16W Metal Oxide
R3012 VRS-CY1JF102JY AA R 1K 1/16W Metal Oxide
R3013 VRS-CY1JF102JY AA R 1K 1/16W Metal Oxide
R3014 VRS-CY1JF102JY AA R 1K 1/16W Metal Oxide
R3018 VRS-CY1JF102JY AA R 1K 1/16W Metal Oxide
R3021 VRS-CY1JF102JY AA R 1K 1/16W Metal Oxide
R3026 VRD-RA2BE331JY AA R 330 1/8W Carbon
R3027 VRS-CY1JF392JY AA R 3.9K 1/16W Metal Oxide
R3028 VRS-CY1JF683JY AA R 68K 1/16W Metal Oxide
R3029 VRS-CY1JF392JY AA R 3.9K 1/16W Metal Oxide
R3030 VRS-CY1JF683JY AA R 68K 1/16W Metal Oxide
R3031 VRS-CY1JF182JY AA R 1.8K 1/16W Metal Oxide
R3032 VRS-CY1JF223JY AA R 22K 1/16W Metal Oxide
R3033 VRS-CY1JF102JY AA R 1K 1/16W Metal Oxide
R3034 VRS-CY1JF182JY AA R 1.8K 1/16W Metal Oxide
R3035 VRS-CY1JF223JY AA R 22K 1/16W Metal Oxide
R3036 VRS-CY1JF102JY AA R 1K 1/16W Metal Oxide
S701 QSW-PA003WJZZ AG R Switch , POWER
S1001 QSW-KA019WJZZ+ AC R Switch , CH UP
S1002 QSW-KA019WJZZ+ AC R Switch , CH DOWN
S1003 QSW-KA019WJZZ+ AC R Switch , VOL UP
S1004 QSW-KA019WJZZ+ AC R Switch , VOL DOWN
S1005 QSW-KA019WJZZ+ AC R Switch , MENU
!
F701 QFS-C3225CEZZ AC R Fuse , 3.15A 250V
FH701 QFSHD1013CEZZ+ AC R Fuse Holder
FH702 QFSHD1014CEZZ+ AC R Fuse Holder
J405 QTANJA136WJZZ R Jack
J1402 QJAKEA094WJ04 R Jack
J1403 QJAKEA094WJ09 R Jack
J1404 QJAKE0210CE02 R Jack
P302 QPLGN0461CEZZA AB R Plug ,4Pin(S)
P601 QPLGN0660CEZZ AC R Plug ,6Pin(F)
P602 LHLDW1104PEZZ AB R Plug
P701 QPLGN0260CEZZ AC R Plug ,2Pin(M)
P702 QPLGN0269GEZZ AB R Plug ,2Pin
P1001 LHLDW1105PEZZ AB R Plug
P1002 QPLGNA110WJZZ AB R Plug ,5Pin(BC)
RMC1001 RRMCUA022WJZZ AG R Remote Receiver
RDA501 PRDARA120WJFW AD R Heat Sink for IC501
RDA601 PRDARA167WJFW AD R Heat Sink for IC601
RDA602 PRDARA361WJFW R Heat Sink for Q602
RDA701 PRDARA119WJFW AF R Heat Sink for IC701
[4] CRT UNIT
Q853 RH-TX0110BMZZ+ AC R TX0110
Q854 RH-TX0110BMZZ+ AC R TX0110
Q855 RH-TX0110BMZZ+ AC R TX0110
Q894 VS2SA1530AR-1Y AB R 2SA1530AR
D859 VHDHSS4148+-1Y AA R Diode
D896 VHEZJ5R6C++1EY AA R Zener Diode , 5.6V
D898 VHDHSS4148+-1Y AA R Diode
L851 VP-MK820K0000+ AB R Peaking 82mH
C851 VCKYPA1HB561K+ AA R 560p 50V Ceramic
C852 VCKYPA1HB271K+ AB R 270p 50V Ceramic
C853 VCKYPA1HB331K+ AA R 330p 50V Ceramic
C880 RC-KZ0016CEZZ AC R 10000p 1.5KV Ceramic
[3] MAIN UNIT
