Ref. No. Part No. « Description Code
D412 RH-EX0614GEZZY X Zener Diode 5.6V AB
D413 RH-EX0614GEZZY X Zener Diode 5.6V AB
D414 RH-EX0614GEZZY X Zener Diode 5.6V AB
D454 RH-EX0628GEZZY X Zener Diode 8.2V AB
D455 VHD1SS133++-1Y X Diode AA
D501 RH-DX0302CEZZY X Diode AB
D502 VHD1SS133++-1Y X Diode AA
D510 RH-DX0441CEZZY X Diode AB
U
D605 RH-DX0255CEZZ X Diode AD
U
D606 RH-DX0302CEZZY X Diode AB
D607 RH-DX0471CEZZY X Diode AB
D621 RH-EX0631GEZZY X Zener Diode 9.1V AB
U
D622 RH-DX0131CEZZY X Diode AB
p
U
D651 VHD1SS244//-1Y X Diode AB
p
U
D652 RH-EX0641GEZZY X Zener Diode 12V AB
p
U
D653 VHD1SS133++-1Y X Diode AA
p
U
D654 VHD1SS133++-1Y X Diode AA
U
D673 RH-DXA006WJZZ X Diode AB
U
D701 RH-DX0477CEZZ X Diode AD
D706 VHD1SS133++-1Y X Diode AA
D707 VHD1SS244//-1Y X Diode AB
D708 VHD1SS244//-1Y X Diode AB
U
D709 RH-DXA006WJZZ X Diode AB
D710 RH-EX0650GEZZY X Zener Diode 16V AB
D711 RH-EX0655GEZZY X Zener Diode AB
D712 RH-DX0468CEZZ X Diode AB
D725 RH-DX0302CEZZY X Diode AB
D726 RH-DX0461CEZZ X Diode AB
D746 VHD1SS133++-1Y X Diode AA
D751 VHD1SS133++-1Y X Diode AA
D752 VHD1SS133++-1Y X Diode AA
D753 VHD1SS133++-1Y X Diode AA
D754 VHD1SS133++-1Y X Diode AA
D755 VHD1SS133++-1Y X Diode AA
D756 VHD1SS133++-1Y X Diode AA
D757 RH-EX0624GEZZY X Zener Diode AB
D759 VHD1SS133++-1Y X Diode AA
D761 RH-EX0611GEZZY X Zener Diode 5.1V AB
D763 VHD1SS133++-1Y X Diode AA
D767 RH-EX0637GEZZY X Zener Diode AB
D904 RH-EX0631GEZZY X Zener Diode 9.1V AB
D905 RH-EX0631GEZZY X Zener Diode 9.1V AB
D906 RH-EX0631GEZZY X Zener Diode 9.1V AB
D907 RH-EX0631GEZZY X Zener Diode 9.1V AB
D908 RH-EX0631GEZZY X Zener Diode 9.1V AB
D909 RH-EX0631GEZZY X Zener Diode 9.1V AB
D2001 VHD1SS133++-1Y X Diode AA
D2040 RH-EX0619GEZZY X Zener Diode, 6.2V AB
D2041 VHD1SS133++-1Y X Diode AA
D2042 VHD1SS133++-1Y X Diode AA
D2060 RH-EX0619GEZZY X Zener Diode, 6.2V AB
TH501 RH-HZ0004GEZZ+ X Thermistor AB
U
VA701 RH-VXA009WJZZ X VARISTOR AB
TP701 QLUGP0102PEZZ X Lug AA
U
PR701 RMPTP0092CEZZ X Packaged Circuit AD
X801 RCRSAA010WJZZ X CRYSTAL AB
CF302 RFILC0449CEZZ+ X Filter AB
CF401 RFILC0446CEZZ+ X Filter AB
L51 VP-CF100K0000Y X Peaking, 10mH AB
L201 VP-XF1R2K0000Y X Peaking 1.2mH AB
L203 VP-XF100K0000Y X Peaking, 10mH AB
DIODES
PACKAGED CIRCUITS
FILTERS AND COILS
PWB-A: DUNTKC290WEA4
MAIN UNIT
Ref. No. Part No. « Description Code
L204 VP-XF100K0000Y X Peaking, 10mH AB
L231 VP-XF680K0000Y X Peaking, 68mH AB
L301 VP-XF8R2K0000Y X Peaking, 8.2mH AB
L401 VP-XF100K0000Y X Peaking, 10mH AB
L671 RCILZ1005CEZZ X LZ1005CE AD
L672 RCILZA021WJZZ X Coil AD
U L701 RCILF0345CEZZ X Coil AC
U L702 RCILF0345CEZZ X Coil AC
L705 RCILP0179CEZZ+ X Coil AB
L728 RCILP0179CEZZ+ X Coil AB
L729 RCILP0179CEZZ+ X Coil AB
L801 VP-XF100K0000Y X Peaking, 10mH AB
L802 VP-XF100K0000Y X Peaking, 10mH AB
L2040 RCILBA007WJZZ X Oscillation Coil AB
SF201 RFILC0405CEZZ X Filter (4.5MHZ) AD
U
T601 RTRNZ0057PEZZ X Transformer AD
p
U
T602 RTRNFA040WJZZ X H-Volt Transformer AT
U
T702 RTRNWA071WJZZ X Transformer AG
C53 VCEA0A1HW105M+ X 1 50V EL. AB
C54 VCEA0A1HW475M+ X 4.7 50V EL. AB
C55 VCEA0A0JW108M+ X 1000 6.3V EL. AB
C58 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C59 VCKYPA1HF103Z+ X 0.01 50V Ceramic AA
C101 VCEA0A0JW108M+ X 1000 6.3V EL. AB
C103 VCEA0A1CW108M+ X 1000 16V EL. AB
C201 VCKYCY1HB102KY X 1000p 50V Ceramic AA
C202 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C203 VCKYCY1HB102KY X 1000p 50V Ceramic AA
C223 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C224 VCEA0A1HW474M+ X 0.47 50V EL. AB
C225 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C227 VCEA0A1HW106M+ X 10 50V EL. AB
C228 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C229 VCEA0A1CW477M+ X 470 16V EL. AB
C231 VCEA0A1EW476M+ X 47 25V EL. AB
C232 VCKYCY1HB222KY X 2200p 50V Ceramic AA
C233 VCEA0A1HW474M+ X 0.47 50V EL. AB
C234 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C235 VCEA0A1HW106M+ X 10 50V EL. AB
C251 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C252 VCEA0A1EW476M+ X 47 25V EL. AB
C302 VCCCCY1HH151JY X 150p 50V Ceramic AA
C303 VCCCCY1HH330JY X 33p 50V Ceramic AA
C304 VCEA0A1HW475M+ X 4.7 50V EL. AB
C306 VCCCCY1HH330JY X 33p 50V Ceramic AA
C307 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C312 VCEA0A1EW476M+ X 47 25V EL. AB
C360 VCEA0A1HW475M+ X 4.7 50V EL. AB
C361 VCEA0A1HW105M+ X 1 50V EL. AB
C362 VCKYCY1EB223KY X 0.022 25V Ceramic AA
C363 VCKYCY1EB223KY X 0.022 25V Ceramic AA
C364 VCEA0A1EW227M+ X 220 25V EL. AB
C365 VCEA0A1HW105M+ X 1 50V EL. AB
C366 VCEA0A1HW106M+ X 10 50V EL. AB
C367 VCEA0A1VW108M+ X 1000 35V EL. AB
C368 VCKYPA1HF103Z+ X 0.01 50V Ceramic AA
C369 VCEA0A1CW227M+ X 220 16V EL. AB
C370 VCEA0A1CW227M+ X 220 16V EL. AB
C371 VCEA0A1EW108M+ X 1000 25V EL. AB
C372 VCEA0A1EW108M+ X 1000 25V EL. AB
C373 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C375 VCEA0A1HW475M+ X 4.7 50V EL. AB
C401 VCEA0A1HW106M+ X 10 50V EL. AB
C402 VCEA0A1HW106M+ X 10 50V EL. AB
TRANSFORMERS
CAPACITORS
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
27F543
26
