Ref. No. Part No. « Description Code
R871 VRD-RA2BE472JY X 4.7k 1/8W Carbon AA
R872 VRD-RA2EE680JY X 68 1/4W Carbon AA
R873 VRD-RM2HD224JY X 220k 1/2W Carbon AA
R874 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R875 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R876 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R877 VRD-RA2BE103JY X 10k 1/8W Carbon AA
U R878 VRS-SV2HC120J X 12 1/2W M-Ox. AB
R1511 VRD-RA2BE101JY X 100 1/8W Carbon AA
R1513 VRS-VV3DB561J X 560 2W M-Ox. AB
R1514 VRD-RA2BE100JY X 10 1/8W Carbon AA
R1515 VRD-RA2BE820JY X 82 1/8W Carbon AA
R1516 VRD-RA2BE820JY X 82 1/8W Carbon AA
R1517 VRD-RA2BE122JY X 1.2k 1/8W Carbon AA
R1518 VRD-RA2BE683JY X 68k 1/8W Carbon AA
R1519 VRD-RA2BE123JY X 12k 1/8W Carbon AA
R1520 VRD-RA2BE683JY X 68k 1/8W Carbon AA
R1521 VRD-RA2BE122JY X 1.2k 1/8W Carbon AA
R1525 VRD-RA2EE560JY X 56 1/4W Carbon AA
R1526 VRD-RA2EE560JY X 56 1/4W Carbon AA
R1527 VRD-RM2HD1R5JY X 1.5 1/2W Carbon AA
R1528 VRD-RM2HD1R5JY X 1.5 1/2W Carbon AA
R1529 VRS-VV3DB221J X 220 2W M-Ox. AB
R1530 VRD-RA2BE122JY X 1.2k 1/8W Carbon AA
FB1501 RBLN-0020CEZZ+ X Ferrite Bead AB
P854 QPLGN0741CEZZ X PLUG (7 PINS) AB
P860 QPLGN0841CEZZ X PLUG (8 PINS) AB
P861 QPLGN0241CEZZ X PLUG (2 PINS) AB
SC850 QSOCV1011CEZZ X CRT Socket AC
RDA850 PRDAR0248PEFW X Heat Sink for IC850 AB
RDA1506 PRDAR5072CEFW X Heat Sink for A1560 AB
RDA1507 PRDAR5072CEFW X Heat Sink for A1507 AB
IC1401 VHITC90A45F-1Y X TC90A45AF AH
Q1401 VS2SD601AR/-1Y X 2SD601AR AB
Q1402 VS2SD601AR/-1Y X 2SD601AR AB
Q1404 VS2SB709AR/-1Y X 2SB709AR AB
L1401 VP-XF100K0000Y X Peaking, 10mH AB
L1402 VP-XF100K0000Y X Peaking, 10mH AB
L1403 VP-XF100K0000Y X Peaking, 10mH AB
L1404 VP-XF220K0000Y X Peaking 22mH AB
L1405 VP-XF220K0000Y X Peaking 22mH AB
L1408 VP-XF100K0000Y X Peaking, 10mH AB
C1401 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1402 VCEA0A1AW227M+ X 220 10V EL. AB
C1403 VCCCCY1HH330JY X 33p 50V Ceramic AA
C1404 VCCCCY1HH181JY X 180p 50V Ceramic AB
C1405 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1406 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1407 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1408 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1409 VCEA0A1CW476M+ X 47 16V EL. AB
C1410 VCKYCY1HB103KY X 0.01 50V Ceramic AA
Ref. No. Part No. « Description Code
C1411 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1412 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1413 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1414 VCE9GA1HW105M+ X 1 50V EL. AB
C1415 VCCCCY1HH120JY X 12p 50V Ceramic AA
C1416 VCCCCY1HH3R0CY X 3p 50V Ceramic AA
C1417 VCCCCY1HH270JY X 27p 50V Ceramic AA
C1418 VCCCCY1HH120JY X 12p 50V Ceramic AA
C1419 VCCCCY1HH3R0CY X 3p 50V Ceramic AA
C1420 VCCCCY1HH270JY X 27p 50V Ceramic AA
C1423 VCFYFA1HA474J+ X 0.47 50V Mylar AB
C1424 VCEA0A1CW107M+ X 100 16V EL. AB
C1425 VCCCCY1HH820JY X 82 pF 50V Ceramic AA
C1429 VCEA0A1CW107M+ X 100 16V EL. AB
C1430 VCKYCY1CB104KY X 0.1 16V Ceramic AA
C1431 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1432 VCKYCY1HB103KY X 0.01 50V Ceramic AA
R1401 VRS-CY1JF821JY X 820 1/16W M-Ox. AA
R1402 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R1403 VRS-CY1JF361JY X 360 1/16W M-Ox. AA
R1415 VRS-CY1JF391JY X 390 1/16W M-Ox. AA
R1416 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R1417 VRS-CY1JF152JY X 1.5k 1/16W M-Ox. AA
R1421 VRS-CY1JF152FY X 1.5k 1/16W M-Ox. AA
R1423 VRS-CY1JF102FY X 1k 1/16W M-Ox. AA
R1427 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R1428 VRD-RA2BE332JY X 3.3k 1/8W Carbon AA
R1429 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R1430 VRS-CY1JF151JY X 150 1/16W M-Ox. AA
P1401 QPLGZ0810CEZZ X PLUG 32" AB
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
CAPACITORS
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
PWB-A: DUNTKA527WEW7
CRT Unit
PWB-A: DUNTKB572WEV0
YC-2LINE Unit
SP1 VSP1206PB708A X Speaker (L) AG
SP2 VSP1206PB708A X Speaker (R) AG
QCNW-B020WJZZ X WIRE (CJ) AC
QCNW-B021WJZZ X WIRE (N) AC
QCNW-B022WJZZ X WIRE (SPEAKER) AC
MISCELLANEOUS PARTS
27F543
32
