Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
23
27R-S50
Ref. No. Part No. ★ Description Code
PICTURE TUBE
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual; electrical components having such features
are identified by å and shaded areas in the Replacement Parts Lists
and Schematic Diagrams. The use of a substitute replacement part
which dose no have the same safety characteristic as the factory
recommended replacement parts shown in this service manual may
create shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
in USA: Contact your nearest SHARP Parts Distributor to order.
For location of SHARP Parts Distributor, Please call Toll-
Free; 1-800-BE-SHARP
★ MARK: SPARE PARTS-DELIVERY SECTION
▲ MARK: X- RAY RELATED PARTS
PWB-A: DUNTKA450WEV2
MAIN UNIT
'åV101 VB68ADT2506*S X Picture Tube (I.T.C) CK
or
VB68QDN891X*S
å L703 RCiLG0038MEZZ X Degaussing Coil AQ
QEARC2702MEZZ X Grounding Strap AF
MSPRT0002MEZZ X Spring AE
QCNW-0239MEZZ X Connecting Cord (DY) AM
PWB-A DUNTKA450WEV2 – MAIN Unit —
PWB-B DUNTK9510WEW3 – CRT Unit —
PWB-H DUNTK9310WEW7 – FRONT A/V Unit —
TUNER
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
å TU51 VTUVTST5UF770 J Tuner AZ
or
VTUENV56D82-1
INTEGRATED CIRCUITS
'åIC201 RH-iX3354CEN1 X I.C. AS
IC351 VHiAN7511//-1 J AN7511 AK
å IC501 VHiLA7841//-1 J LA7841 AM
å IC701 VHiTEA1507/-1 J TEA1507P/N1 AL
å IC702 RH-FX0034CEZZ J PC817 AE
or
RH-FX0002GEZZ
or
RH-FX0029CEZZ
å IC751 VHiKA7809AP-1 J KIA7809API AE
å IC771 VHiKA7805AP-1 J KIA7805API AE
or
VHiTA7805S/-1
IC2001 RH-iX3492CEZZQ X TMPA8700CPF AT
IC2040 VHiPST994C/-1 J PST994C AD
IC2102 VHiBR2416E2-1 J BR24C16F AK
or
VHiSLA24C16-1
IC3001 VHiCXA2074Q-1 J CXA2074Q AY
IC3371 VHiAN7511//-1 J AN7511 AK
TRANSISTORS
Q101 VS2SC3198-Y-1 J 2SC3198-Y AA
or
VS2SC945AQ/-1
Q201 VS2SC2735//1E J 2SC2735 AC
Q301 VS2SD601AR/-1 J 2SD601AR AC
or
VS2SC3928R/-1
Q451 VS2SB709AR/-1 J 2SB709AR AC
Q452 VS2SA1266-Y-1 J 2SA1266-Y AA
Q491 VS2SB709AR/-1 J 2SB709AR AC
Q601 VS2SC2482//-1 J 2SC2482 AD
å Q602 VS2SD2539//1E J 2SD2539 AP
or
VS2SD2634++-1
Q631 VS2SC3198-Y-1 J 2SC3198-Y AA
or
VS2SC945AQ/-1
Q651 VS2SB709AR/-1 J 2SB709AR AC
Q652 VS2SA1266-Y-1 J 2SA1266-Y AA
Q653 VS2SD601AR/-1 J 2SD601AR AC
å Q701 VSSPP07N60C-1 X FET AF
or
VSSPP04N60C-1
or
VS2SK2708//1E
or
VS2SK2645//-G
or
VSSTP6NC60+-1
or
VSSTP6NC60F-1
or
VSSTP7NB60F-1
å Q702 VS2SC3198-Y-1 J 2SC3198-Y AA
or
VS2SC945AQ/-1
Q703 VS2SB709AR/-1 J 2SB709AR AC
To Next Page
