Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
47
32F630
32F631
PWB-H: DUNTKB569WEV0
DF MODULE UNIT (Continued)
R1686 VRD-RA2BE103J∗ X 10k 1/8W Carbon AA
R1687 VRD-RA2BE103J∗ X 10k 1/8W Carbon AA
R1688 VRD-RA2BE473J∗ X 47k 1/8W Carbon AA
R1689 VRD-RA2BE823J∗ X 82k 1/8W Carbon AA
R1690 VRD-RA2BE822J∗ X 8.2k 1/8W Carbon AA
R1691 VRD-RA2BE823J∗ X 82k 1/8W Carbon AA
R1695 VRD-RA2BE224J∗ X 220k 1/8W Carbon AA
R1697 VRD-RA2EE1R0J∗ X 1 1/4W Carbon
R1698 VRD-RA2BE472J∗ X 4.7k 1/8W Carbon AA
R1699 VRD-RA2BE562J∗ X 5.6k 1/8W Carbon AA
MISCELLANEOUS PARTS
P1602 QPLGN0741CEZZ X Plug, 7Pin(XA) AB
P1603 QPLGN0161FJZZ X Plug, 6Pin(XB) AB
P1604 QPLGN0157FJZZ X Plug, 2Pin(XC)
RDA1680 PRDAR0135PEFW X Heat Sink for Q1680
SG1681 QSPGH0025CEZZ X Spark Gap
PWB-S: DUNTKB571WEV1
AUDIO UNIT
INTEGRATED CIRCUIT
IC3501 VHiNJW1140G-1Y X NJW1140GK1
DIODES
D3501 RH-EX0619GEZZ∗ X Zener Diode, 6.2V AB
D3502 RH-EX0619GEZZ∗ X Zener Diode, 6.2V AB
CAPACITORS
C3501 VCQYTA1HM104J+ X 0.1 50V Mylar AB
C3502 VCFYFA1HA334J+ X 0.33 50V AB
C3503 VCKYCY1HB822K∗ X 8200p 50V Ceramic AA
C3509 VCEA0A1HW105M+X 1 50V Electrolytic AA
C3510 VCEA0A1HW105M+X 1 50V Electrolytic AA
C3511 VCEA0A1HW105M+X 1 50V Electrolytic AA
C3512 VCEA0A1HW105M+X 1 50V Electrolytic AA
C3513 VCEA0A1HW105M+X 1 50V Electrolytic AA
C3514 VCEA0A1CW476M+X 47 16V Electrolytic AA
C3515 VCKYCY1HB103K∗ X 0.01 50V Ceramic AA
C3531 VCQYTA1HM104J+ X 0.1 50V Mylar AB
C3533 VCKYCY1EB223K∗ X 0.022 25V Ceramic AA
C3539 VCFYFA1HA334J+ X 0.33 50V Mylar AB
C3540 VCEA0A1HW105M+X 1 50V Electrolytic AA
C3541 VCEA0A1HW105M+X 1 50V Electrolytic AA
C3694 VCE9GA1HW475M+X 4.7 50V Electrolytic AB
C3695 VCE9GA1HW475M+X 4.7 50V Electrolytic AB
RESISTORS
R3501 VRS-CY1JF472J∗ X 4.7k 1/16W Metal Oxide AA
R3502 VRS-CY1JF221J∗ X 220 1/16W Metal Oxide AA
R3531 VRS-CY1JF221J∗ X 220 1/16W Metal Oxide AA
R3532 VRS-CY1JF221J∗ X 220 1/16W Metal Oxide AA
R3533 VRS-CY1JF221J∗ X 220 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
P3004 QPLGN0242CEZZ X Plug, 2Pin(TP3001-3002) AA
P3006 QPLGZ0610CEZZ X Plug, 6Pin AB
P3007 QPLGZ0610CEZZ X Plug, 6Pin AB
MISCELLANEOUS PARTS
SP1, SP2 VSP1206PB648A X Speaker(32F631) AG
SP1, SP2 VSP1206PB708A X Speake(32F630) AH
QCNW-A475WJZZ X Connecting Cord(32F631) AC
QCNW-B174WJZZ X Connecting Cord(32F630) AD
QCNW-B175WJZZ X Connecting Cord AC
QCNW-B176WJZZ X Connecting Cord AC
QCNW-B177WJZZ X Connecting Cord AC
QCNW-B178WJZZ X Connecting Cord AE
QCNW-B179WJZZ X Connecting Cord AC
QCNW-B240WJZZ X Connecting Cord(32F631) AE
QCNW-B241WJZZ X Connecting Cord(32F631) AB
SUPPLIED ACCESSORIES
RRMCGA108WJSA X Infrared R-C Unit
TiNS-A583WJZZ X Opearation Manual(32F630) AE
TiNS-A660WJZZ X Opearation Manual(32F631) AE
TGAN-0001GJZZ X Guarantee Card AB
PACKING PARTS
(NOT REPLACEMENT ITEM)
SPAKCA474WJZZ - Packing Case(32F630) —
SPAKCA590WJZZ - Packing Case(32F631) —
SPAKP0110GJZZ - Wrapping Paper —
SPAKX0131GJZZ - Buffer Material(32F631) —
SPAKXA190WJZZ - Buffer Material(32F630) —
SSAKA0101GJZZ - Polyethylene Bag —
