Sharp AE-A12B User Manual

50
AH-A07BE-C/09BE-C
AH-A07BE/09BE/12BE
AY-A07BE-C/09BE-C
AY-A07BE/09BE/12BE
REPLACEMENT PARTS LIST
CABINET AND UNIT PARTS
1- 1 LBSHCA022JBE0 Bushing 1 AE
1- 2 CMOTLA916JBEZ Fan motor [AU-A09BE/A09BE-C, AE-A09BE/A09BE-C] 1 BK
1- 2 CMOTLA917JBEZ Fan motor [AU-A12BE, AE-A12BE] 1 BK
1- 3 NFANPA094JBEZ Propeller fan 1 AK
1- 4 LANGKA124JBPZ Fan motor angle 1 AK
1- 5 LANGKA123JBPZ Fan motor angle sub [AE-A12BE] 1 AE
1- 5 LANGKA127JBPZ Fan motor angle sub [AU-A12BE, AE-A09BE/A09BE-C] 1 AE
1- 5 LANGKA128JBPZ Fan motor angle sub [AU-A09BE/A09BE-C] 1 AG
1- 6 PSKR-A220JBWZ Bulkhead [AU-A12BE] 1 AG
1- 6 PSKR-A215JBWZ Bulkhead [AU-A09BE/A09BE-C, AE-A09BE/A09BE-C/A12BE] 1 AR
1- 7 PFTA-A092JBFA Side cover 1 AQ
1- 8 PCOV-A616JBPZ Protect cover 1 AE
1- 9 GCAB-A195JBTA Front panel 1 BC
1-10 GCAB-A204JBTA Rear cabinet [AU-A09BE/A09BE-C, AE-A09BE/A09BE-C/A12BE] 1 BD
1-10 GCAB-A206JBTA Rear cabinet [AU-A12BE] 1 BD
1-11 GCAB-A197JBTA Top cover 1 AX
1-12 GGADFA037JBFA Fan guard 1 AT
1-13 JHNDPA011JBFA Holder 1 AS
1-14 PSPF-A800JBEZ Compressor cover [AU-A09BE/A09BE-C] 1 AU
1-14 PSPF-A799JBEZ Compressor cover [AU-A12BE] 1 AU
1-14 PSPF-A774JBEZ Compressor cover [AE-A09BE] 1 AW
1-14 PSPF-A831JBEZ Compressor cover [AE-A09BE-C] 1 AR
1-14 PSPF-A775JBEZ Compressor cover [AE-A12BE] 1 AT
1-15 TSPC-D657JBRZ Name Label [AE-A09BE] 1 AD
1-15 TSPC-E041JBRZ Name Label [AE-A09BE-C] 1 AD
1-15 TSPC-D659JBRZ Name Label [AE-A12BE] 1 AD
1-15 TSPC-D661JBRZ Name Label [AU-A09BE] 1 AF
1-15 TSPC-E043JBRZ Name Label [AU-A09BE-C] 1 AD
1-15 TSPC-D668JBRZ Name Label [AU-A12BE] 1 AE
1-16 TLABBA149JBRZ Sharp badge 1 AG
1-17 CCAB-A292JBKZ Front panel ass'y 1 BE
1-18 CCAB-A293JBKZ Rear cabinet ass'y
[AU-A09BE/A09BE-C,AE-A09BE/A09BE-C/A12BE] 1BE
1-18 CCAB-A295JBKZ Rear cabinet ass’y [AU-A12BE] 1 BE
1-19 DCAB-A099JBKZ Top cover ass’y [AU-A09BE] 1 AU
1-19 DCAB-A123JBKZ Top cover ass’y [AU-A09BE-C] 1 AY
1-19 DCAB-A100JBKZ Top cover ass’y [AU-A12BE] 1 AX
1-19 DCAB-A097JBKZ Top cover ass’y [AE-A09BE] 1 AX
1-19 DCAB-A117JBKZ Top cover ass’y [AE-A09BE-C] 1 AY
1-19 DCAB-A098JBKZ Top cover ass’y [AE-A12BE] 1 AX
1-20 FFTA-A014JBKZ Side cover ass’y 1 AT
1-21 CCHS-A747JBTA Base pan ass’y [AU-A09BE, AE-A09BE] 1 BC
1-21 CCHS-A748JBTA Base pan ass’y
[AU-A09BE-C,AE-A09BE-C,AU-A12BE,AE-A12BE] 1BD
1-23 PFPFPB911JBEZ Motor angle cushion 1 AC
1-24 PSEL-C045JBEZ Motor angle cushion 1 AB
1-25 PSEL-C051JBEZ Side cover seal 1 AE
1-26 PSEL-C120JBEZ Side cover seal 1 AC
1-27 PSEL-C121JBEZ Side cover seal 1 AC
1-28 PSEL-C133JBEZ Box insulator 1 AC
1-29 PSEL-C119JBEZ Box insulator 1 AE
1-30 PSEL-C128JBEZ Insulator 1 AD
1-31 PSEL-C048JBEZ F.panel insulator 1 AC
1-32 PSEL-C049JBEZ F.panel insulator 1 AC
1-33 PSEL-C050JBEZ Bulkhead insulator 1 AG
1-34 PSEL-C072JBEZ Insulator [AU-A09BE/A09BE-C, AE-A09BE/A09BE-C/A12BE] 1 AE
1-34 PSEL-C073JBEZ Insulator [AU-A12BE] 1 AF
1-35 PSEL-C132JBEZ F.panel insulator 1 AA
CONTROL BOX PARTS
2- 1 QW-IZA013JBZZ Compressor cord [AU-A09BE, AE-A09BE] 1 AP
2- 1 QW-IZA029JBZZ Compressor cord [AU-A09BE-C, AE-A09BE-C] 1 AQ
2- 1 QW-IZA015JBZZ Compressor cord [AU-A12BE, AE-A12BE] 1 AL
2- 2 RC-HZA389JBE0 Running capacitor [AU-A09BE/A12BE, AE-A09BE/A12BE] 1 BC
2- 2 RC-HZA301JBE0 Running capacitor [AU-A09BE-C, AE-A09BE-C] 1 AX
2- 3 RC-HZA419JBZZ Fan motor capacitor [AU-A09BE/A09BE-C,AE-A09BE/A09BE-C] 1 AP
2- 3 RC-HZA308JBZZ Fan motor capacitor [AU-A12BE, AE-A12BE] 1 AM
2- 4 QTANZA002JBZZ Terminal board [AU-A09BE/A09BE-C/A12BE] 1 AN
2- 4 QTANZA003JBZZ Terminal board [AE-A09BE/A09BE-C/A12BE] 1 AR
2- 5 LHLD-0261JBM0 Cord holder 1 AB
2- 6 TLABCB407JBRZ Wiring diagram [AE-A09BE] 1 AC
2- 6 TLABCB574JBRZ Wiring diagram [AE-A09BE-C] 1 AD
2- 6 TLABCB409JBRZ Wiring diagram [AE-A12BE] 1 AC
2- 6 TLABCB410JBRZ Wiring diagram [AU-A09BE] 1 AC
2- 6 TLABCB575JBRZ Wiring diagram [AU-A09BE-C] 1 AG
2- 6 TLABCB414JBRZ Wiring diagram [AU-A12BE] 1 AC
REF. NO. PART NO. DESCRIPTION Q'TY CODE
[AU-A09BE/A09BE-C/A12BE, AE-A09BE/A09BE-C/A12BE]
