ELECTRICAL PARTS
For Models AY-A07BE/A07BE-C, AH-A07BE/A07BE-C, AE-A07BE/A07BE-C, AU-A07BE and AU-A07BE-C
DESCRIPTION MODEL REMARKS SITE
Compressor QK134PA13A 220 - 240V, 50Hz, 620W AE/AU-A07BE
Compressor RH135VHST 220 - 240V, 50Hz, 650W AE-A07BE-C
Compressor RH130VHST 220 - 240V, 50Hz, 650W AU-A07BE-C
Indoor fan motor ML-A915 220 - 240V, 50Hz AY, AH
Outdoor fan motor ML-A592 220 - 240V, 50Hz AE, AU
Indoor fan motor capacitor – 400V, 2µF AY, AH
Outdoor fan motor capacitor – 400V, 1.5µF AE, AU
Running capacitor – 370V, 25µF AE/AU-A07BE
Running capacitor – 400V, 25µF AE/AU-A07BE-C
Transformer – Primary; AC 230V, 50Hz AY, AH
Secondary; AC16.7V, 50Hz
Fuse – 250V, 3A AY, AH
Reverse valve VK1100B, 1400B – AE
Reverse valve coil – 220 - 240V, 50/60Hz AE
For Models AY-A09BE/A09BE-C, AH-A09BE/A09BE-C, AE-A09BE/A09BE-C, AU-A09BE and AU-A09BE-C
DESCRIPTION MODEL REMARKS SITE
Compressor QK164PA13A 220 - 240V, 50Hz, 780W AE/AU-A09BE
Compressor RH165VHET 220 - 240V, 50Hz, 800W AE-A09BE
Compressor RH154VHST 220 - 240V, 50Hz, 750W AU-A09BE
Indoor fan motor ML-A915 220 - 240V, 50Hz AY, AH
Outdoor fan motor ML-A916 220-240V,50Hz 220-230V,60Hz AE, AU
Indoor fan motor capacitor – 400V, 2µF AY, AH
Outdoor fan motor capacitor – 400V, 1.5µF AE, AU
Running capacitor – 400V, 30µF AE/AU-A09BE
Running capacitor – 400V, 25µF AE/AU-A09BE-C
Transformer – Primary; AC 230V, 50Hz AY, H
Secondary; AC16.7V, 50Hz
Fuse – 250V, 3A AY, AH
Reverse valve VK1100B, 1400B – AE
Reverse valve coil – 220 - 240V, 50/60Hz AE
For Model AY-A12BE, AH-A12BE , AE-A12BE and AU-A12BE
DESCRIPTION MODEL REMARKS SITE
Compressor RH207VHET 220 - 240V, 50Hz, 1000W AE, AU
Indoor fan motor ML-A915 220 - 240V, 50Hz AY, AH
Outdoor fan motor ML-A917 220-240V,50Hz 220-230V,60Hz AE, AU
Indoor fan motor capacitor – 400V, 2µF AY, AH
Outdoor fan motor capacitor – 400V, 2µF AE, AU
Running capacitor – 400V, 30µF AE, AU
Transformer – Primary; AC 230V, 50Hz AY, AH
Secondary; AC16.7V, 50Hz
Fuse – 250V, 3A AY, AH
Reverse valve VK2100B, 2400B – AE
Reverse valve coil – 220 - 240V, 50/60Hz AE
