PART NAMES
1 Oven door with see-through window
2 Safety door latches
The oven will not operate unless the
door is securely closed.
3 Door hinges
4 Door seals and sealing surfaces
5 Turntable motor shaft
6 Removable turntable support
7 Removable turntable
Place the turntable on the turntable
support securely. The turntable will
rotate clockwise or counterclockwise.
Only remove for cleaning.
8 Ventilation openings (Rear)
9 Oven light
It will light when oven is operating.
10 Waveguide cover: DO NOT REMOVE.
11 Door open handle
Pull to open door.
MICROWAVE OVEN PARTS
TOUCH CONTROL PANEL
1
2
11
3
4
7
6
910 8
5
DEF. QTY.
CHECK
ON
10 109
8,118,11
8,11
8
8
10
Control panel display
Words will light in the
display to indicate features
and cooking instructions.
Number indicates page on which there are a feature description and usage information.
NOTE:
Open the door to press the pads. Although STOP/CLEAR pad can
be used even if the door is closed.
START/MINUTE PLUS pad can be used when the door is closed.
TOUCH CONTROL PANEL
DOOR CLOSED
