14-1
A7121CA
MECHANICAL PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety
characteristics identified in this manual ; electrical
components having such features are identified by #
and shaded areas in the Replacement Parts Lists and
Schematic Diagrams. The use of a substitute replacement
part which does no have the same safety characteristic
as the factory recommended replacement parts shown in
this service manual may create shock, fire or other
hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please
furnish the following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
in USA: Contact your nearest SHARP Parts Distributor to
order. For location of SHARP Parts Distributor,
Please call Toll-Free; 1-800-BE-SHARP
Cabinet and Packing
LISTE DES PIÈCES
MÉCHANIQUES
CHANGE DES PIECES
Les pièces de rechange qui pr élelesentent ces caract
éleristiques sp éleciales de s élecurit éle, sont identifi
élees dans ce manuel : les pièces élelectriques qui pr
élesentent ces particularit éles, sont rep éler élee par la
marque # et sont hachur élees dans les listes de pièces
et dans les diagrammes sch élematiques.
La substitution d’une pièce de rechange par une autre qui
ne pr éLesente pas les m éoemes caract éleristiques de
s élecurit éle que la pièce recommand élee parl’usine et
dans ce manuel de service, peut provoquer une
éLelectrocution, un incendie ou toutautre sinistre.
"COMMENT COMMANDER LES PIECES DE RECHANGE"
Pour que votre commande soit rapidement et correctement
remplie, veuillez fournir les renseignements suivants.
1. NUMERO DU MODELE 2. NO. DE REF
3. NO. DE PIECE 4. DESCRIPTION
in CANADA: Contact SHARP Electronics of Canada
Limited Phone (416) 890-2100
Ref. No. Part No. Description
A1 9HS1EM021646 FRONT CABINET A7121UH
A3 9HS1EM322535 CONTROL PLATE A7121UH
A4 9HS1EM021681 REAR CABINET A7121UH
A6# ---------- RATING LABEL A7121UH
A7 9HS1EM322170 FUNCTION KNOB L2530JA
A9 9HS1EM021648 STAND COVER A7121UH
A10 9HS1EM423989 CONNECTER CAP A7120UH
A11 9HS1EM322525 SENSOR LED LENS A7121UH
A12 9HS1EM422534 STAND RUBBER FOOT L4300UA
A15 9HS1EM021647 FRONT COVER A7121UH
A20 ---------- POP LABEL A7121UH
B1 9HS1EM423986 SPEAKER HOLDER A7120UH
B2 9HS1EM321626B TILT STAND HOLDER L2500UA
B3 9HS1EM321428 STAND HOLDER L2500UA
B4 9HS1EM221489 JACK HOLDER A7120UH
B5 9HS1EM021568 LCD HOLDER A7120UH
B8 9HS1EM221544 ARM ASSEMBLY A7120UH
B9 9HS1EM322373 MODULE PCB HOLDER P7150UZ
B13 9HS1EM420551 RUBBER CUSHION L0170UA
B14 9HS1EM420019 CLOTH(10X190XT0.3) L0200UA
CL1401 9HSX1A7120-006 WIRE ASSEMBLY 33PIN FFC 33PIN/80MM
CL1402 9HSX1A7121-002 WIRE ASSEMBLY 25PIN FFC 25PIN/80MM
CL1411 9HSX1A7120-007 WIRE ASSEMBLY 20PIN LVDS 20PIN/100MM
L2 9HSGBJP3080 SCREW P-TIGHT M3X8 BIND HEAD+
L3 9HSGBHP3100 SCREW P-TIGHT 3X10 BIND HEAD+
L5 9HSGBHP4180 SCREW P-TIGHT M4X18 BIND HEAD+
L6 9HSGCJP3100 SCREW P-TIGHT M3*10 WASHERHEAD+
L12 9HSGBJS3080 SCREW S-TIGHT M3X8 BIND HEAD+
L19 9HS1PM420450 SEMS SCREW M3X6 J5600
L20 9HSGBHB4080 SCREW B-TIGHT M4X8 BIND HEAD+ BLK
L21 9HS1EM422564 DOUBLE SEMS SCREW M3X8 M3X8
