Sharp LC-32LE280X Service Manual

LC-32LE280X/LC-40LE280X
8
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
L7801 RCILPB498WJQZ+ COIL
LUG7001 QEARPA210WJQZ+ AB LUG
LUG7002 QEARPA210WJQZ+ AB LUG
LUG7003 QEARPA210WJQZ+ AB LUG
P7001 QPLGNA997WJZZ AD AC HEADER
P7101 QPLGNB203WJZZ MAIN CONNECTOR
P7801 QPLGNB195WJZZ LED CONNECTOR
Q7002 VSR6515EN//-1 PRIMARY MOSFET
Q7801 RH-TXA078WJZZY AG TRANSISTOR
Q7802 VSMDD4N20//-1Y AE BOOST MOSFET
Q7803 VS2N7002KA+-1Y DIMMING MOSFET
R7001 RR-HZ0041CEZZY AB RESISTOR
R7002 VRS-CY1JF102JY AA RESISTOR
R7004 VRS-CY1JF154JY AA RESISTOR
R7005 VRD-RA2BE224JY AA RESISTOR
R7006 VRD-RA2BE224JY AA RESISTOR
R7007 VRD-RA2BE224JY AA RESISTOR
R7008 VRD-RA2BE102JY AA RESISTOR
R7009 VRS-TV1JD121JY AA RESISTOR
R7010 VRS-RG3DB473J+ AB RESISTOR
R7011 VRS-RG3DB473J+ AB RESISTOR
R7014 VRN-VV3ABR22JY AC RESISTOR
R7016 RR-HZ0014GEZZY AE RESISTOR
R7017 VRS-CY1JF394JY AA RESISTOR
R7018 VRD-RA2BE1R0JY AA RESISTOR
R7019 VRS-TW2HF100JY AA RESISTOR
R7020 VRS-TV1JD100JY AA RESISTOR
R7101 VRS-CY1JF182JY AA RESISTOR
R7102 VRS-CY1JF271JY AA RESISTOR
R7104 VRS-CY1JF153JY AA RESISTOR
R7106 VRS-CY1JF562JY AA RESISTOR
R7107 VRS-CY1JF123JY AA RESISTOR
R7108 VRS-CY1JF823JY AA RESISTOR
R7109 VRD-RM2HD100JY AA RESISTOR
R7114 VRS-CY1JF470JY AA RESISTOR
R7115 VRS-CY1JF470JY AA RESISTOR
R7801 VRS-CY1JF474JY AA RESISTOR
R7802 VRD-RA2BE474JY AA RESISTOR
R7803 VRS-CY1JF683JY AA RESISTOR
R7804 VRS-CY1JF513JY AA RESISTOR
R7805 RR-SZA294WJZZY AB RESISTOR
R7806 RR-SZA294WJZZY AB RESISTOR
R7809 VRS-CY1JF100FY AB RESISTOR
R7810 VRS-TV1JD470JY AA RESISTOR
R7811 VRS-TV1JD224JY AA RESISTOR
R7812 VRS-CY1JF103JY AA RESISTOR
R7813 VRS-CY1JF223JY AA RESISTOR
R7814 VRS-CY1JF104JY AA RESISTOR
R7815 VRS-CY1JF301JY AA RESISTOR
R7816 RR-SZA268WJZZY AB RESISTOR
R7818 RR-SZA297WJZZY RESISTOR
R7820 VRS-TV1JD000JY AA RESISTOR
R7830 VRS-CY1JF102JY AA RESISTOR
RDA7101 PRDARB271WJFW AF HEATSINK
T7001 RTRNWA481WJQZ TRANSFORMER
TH7001 RH-HXA013WJZZ+ AD THERMISTOR
VA7001 RH-VXA263WJLA AD VARISTOR
[5] POWER UNIT : DUNTKG710FM02 ( LC-40LE280X/WH )
C7001 RC-F ZA560WJN1 CAPACITOR
C7002 VCKY CY1HB102KY AA CAPACITOR
C7003 VCCC CY1HH220JY AA CAPACITOR
C7004 RC-F ZA560WJN1 CAPACITOR
C7006 VCCC CY1HH220JY AA CAPACITOR
C7009 RC-F ZA709WJQZ AE CAPACITOR
C7012 RC-K ZB016WJN1 CAPACITOR
C7014 RC-K ZB009WJN1 CAPACITOR
C7015 RC-K ZB009WJN1 CAPACITOR
C7016 RC-K ZB009WJN1 CAPACITOR
C7030 RC-E ZC026WJZZ CAPACITOR
C7031 RC-E ZB326WJZZ+ AB CAPACITOR
C7032 RC-E ZC026WJZZ CAPACITOR
C7101 VCKY PA2HB471K+ AA CAPACITOR
C7103 VCCS PA2HL220K+ AB CAPACITOR
C7108 VCKY CY1EB103KY AA CAPACITOR
C7111 RC-K ZB028WJZZ+ AD CAPACITOR
C7112 RC-K ZB028WJZZ+ AD CAPACITOR
C7113 VCCC CY1HH331JY AA CAPACITOR
C7116 RC-K ZB117WJZZ+ AD CAPACITOR
C7131 RC-E ZB384WJZZ+ AE CAPACITOR
C7132 RC-E ZB381WJLA CAPACITOR
C7133 RC-E ZA169WJZZ+ AD CAPACITOR
C7134 RC-E ZA172WJLA AF CAPACITOR
C7801 VCKY CY1HB103KY AA CAPACITOR
C7802 RC-K ZB048WJQZY AB CAPACITOR
[4] POWER UNIT : DUNTKG709FM02 ( LC-32LE280X/WH )
