PARTS GUIDE
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-40/46/52/60LE820UN
PartsGuide
[1] PRINTED WIRING BOARD
ASSEMBLIES
[2] LCD PANEL
[3] CABINET PARTS (LC-40LE820UN)
[4] CABINET PARTS (LC-46LE820UN)
[5] CABINET PARTS (LC-52LE820UN)
[6] CABINET PARTS (LC-60LE820UN)
[7] SUPPLIED ACCESSORIES
[8] PACKING PARTS
(NOT REPLACEMENT ITEM)
(LC-40LE820UN)
[9] PACKING PARTS
(NOT REPLACEMENT ITEM)
(LC-46LE820UN)
[10] PACKING PARTS
(NOT REPLACEMENT ITEM)
(LC-52LE820UN)
[11] PACKING PARTS
(NOT REPLACEMENT ITEM)
(LC-60LE820UN)
[12] SERVICE JIGS
(USE FOR SERVICING)
CONTENTS
LCD COLOR TELEVISION
LC-40LE820UN
LC-46LE820UN
LC-52LE820UN
LC-60LE820UN
MODELS
No. S30F140LE820U
