Sharp MX-B201D Technical Handy Guide

SHARP
TEST SIMULATION
27
The following pages contain information regarding test simulations. For a detailed description for each
test simulation, please refer to the MX-B201D Service Manual.
Entry Code:
1
Scanner Self Test
1
Scanner operations test
2
Scanner home position status display
6
Scanner operation aging
2
RSPF Self Test
1
RSPF aging
2
RSPF sensor status display
3
RSPF motor operation check
6
RSPF resist clutch operation check
8
RSPF paper feed solenoid operation check
9
RSPF reverse solenoid operation check
3
Finishing Operation & Test
3
Shifter operation check
5
Lamp Operation & Test
1
LCD/LED test
2
Fusing lamp cooling fan operation check
3
Copy lamp check
6
System Load Operation & Test
1
Paper feed solenoid check
2
Resist solenoid check
7
Device Aging Operation & Test
1
Paper feed ageing test setting
6
Interval ageing cycle timer set up
8
Warm up time display setting
8
High Voltage Operation Test
1
Developing bias output
2
Main charger output (Grid HIGH)
3
Main charger output (Grid LOW)
6
Transfer charger output
9
Duplex Operation & Test
1
Duplex motor normal rotation check
2
Duplex motor reverse rotation check
4
Duplex motor rotating speed adjustment
10
Toner Motor Operation & Test
-
Toner motor operation check
14
Clear / Cancel
-
Trouble cancel (excluding U2 trouble).
16
U2 Clear / Cancel
-
U2 trouble cancel
20
Maintenance Counter Clear / Cancel
1
Maintenance counter clear
21
Maintenance Cycle Configuration
1
Maintenance cycle setting
22
Data Output & Check
1
Maintenance counter display
2
Maintenance preset display
4
JAM total counter display
5
Total counter display
6
Developer counter display
8
RSFP counter display
11
FAX related counter display
12
Drum counter display
13
CRUM type display
14
ROM version display
16
Duplex counter display
17
Copy counter display
18
Printer counter display
19
Scanner mode counter display
20
Password display
21
Scanner counter display
22
RSPF JAM counter display
24
Data Counter & Clear
1
JAM total counter clear
4
SPF counter clear
5
Duplex counter clear
6
Developer counter clear
7
Drum copy counter clear
