Sharp Plasmacluster AE-A09DJ User Manual

4
PART NAMES
1 Inlet (Air)
2 Open Panel
3 Air Filters
4 AUX. Button
5 RECEIVER Window
6 Power Supply Cord
7 Indicator Panel
8 Vertical Adjustment Louvres
9 Horizontal Adjustment Louvres
0 Outlet (Air)
q Remote Control
w AUTO FAN SPEED Lamp
(green )
e FAN SPEED Lamp (green )
r PLASMACLUSTER Lamp (blue,
green)
t TIMER Lamp (orange )
y OPERATION Lamp (red )
OUTDOOR UNIT
NOTE: Actual units might vary slightly from those shown above.
INDOOR UNIT
1
2
3
4
5
6
7
8
9
0
q
u Inlet (Air)
i Refrigerant Tube and
Interconnecting Cord
o Drainage Hose
p Outlet (Air)
w
e
r
t
y
u
i
o
p
