RS-232C command table
How to read the command table
Command: Command eld (See page 33.)
Direction: W When the “Parameter” is set in the parameter eld (see page 33), the command functions as described
under “Control/Response Contents”.
R The returned value indicated under “Reply” can be obtained by setting “????”, “
?” or “???+”
(repeater control) in the parameter eld (see page 33).
Parameter: Parameter eld (See page 33.)
Reply: Response (Returned value)
* : “●” indicates a command which can be used in standby mode/input signal waiting mode regardless of the
STANDBY MODE setting.
“○” indicates a command which cannot be used in standby mode/input signal waiting mode when STANDBY
MODE is set to LOW POWER.
“–” indicates a command which cannot be used in standby mode/input signal waiting mode regardless of the
STANDBY MODE setting.
TIPS
• RSET and MUTE can be used in input signal waiting mode when STANDBY MODE is set to STANDARD.
Power control/Input mode selection
Function Command Direction Parameter Reply Control/Response contents *
POWER CONTROL POWR W 0 Switches to standby mode.
●
1 Returns from standby mode.
R 0 Standby mode
1 Normal mode
2 Input signal waiting mode
INPUT MODE SELECTION INPS W 0 Toggle change for input mode. Terminals not selected in INPUT SELECT cannot
be selected.
●
1 DVI-I
2 D-SUB[RGB]
“ERR” when other than RGB is selected for D-SUB of INPUT SELECT.
3 D-SUB[COMPONENT]
“ERR” when other than COMPONENT is selected for D-SUB of INPUT SELECT.
4 D-SUB[VIDEO]
“ERR” when other than VIDEO is selected for D-SUB of INPUT SELECT.
9 HDMI1[AV]
“ERR” when PC is selected for HDMI1 of INPUT SELECT.
10 HDMI1[PC]
“ERR” when AV is selected for HDMI1 of INPUT SELECT.
12 HDMI2[AV]
“ERR” when PC is selected for HDMI2 of INPUT SELECT.
13 HDMI2[PC]
“ERR” when AV is selected for HDMI2 of INPUT SELECT.
14 DisplayPort
R 1 DVI-I
●
2 D-SUB[RGB]
3 D-SUB[COMPONENT]
4 D-SUB[VIDEO]
9 HDMI1[AV]
10 HDMI1[PC]
12 HDMI2[AV]
13 HDMI2[PC]
14 DisplayPort
