5
R-120DG
R-120DP
R-120DSC
∆
∆
PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
*
*
*
∆
*
∆
*
ELECTRIC PARTS
1- 1 QSW-MA137WRE0 Secondary interlock switch & door sensing switch 2 AH
1- 2 FFS-BA027WRKZ
C/T fuse (120˚C, 13A) & monitor switch (AM51620C53Y1) assembly
1AS
1- 3 FACCDA079WRE0 Power supply cord 1 AF
1- 4 QSOCLA021WRE0 Oven lamp socket 1 AH
1- 5 FH-DZA095WRKZ High voltage rectifier 1 AQ
1- 6 RC-QZA209WRE0 High voltage capacitor 1 AX
1- 7 RMOTEA383WRE0 Fan motor 1 AV
1- 8 RV-MZA195WRE0 Magnetron 1 BK
1- 8 RV-MZA198WRE0 Magnetron (Iinterchangeable) 1 BN
1- 9 RLMPTA068WRE0 Oven lamp 1 AG
1-10 RMOTDA211WRE0 Turntable motor 1 AS
1-10 RMOTDA186WRE0 Turntable motor (Iinterchangeable) 1 AW
1-11 RTHM-A117WRE0 Thermal cut-out 95˚C 1 AQ
1-12 RTRN-A606WRZZ Power transformer 1 BM
CABINET PARTS
2- 1 GCABUA779WRPZ Outer case cabinet [R-120DSC] 1 BB
2- 1 GCABUA781WRPZ Outer case cabinet [R-120DG] 1 BB
2- 1 GCABUA783WRPZ Outer case cabinet [R-120DP] 1 BB
2- 2 GDAI-A325WRWZ Bottom plate 1 AF
2- 3 GLEGPA074WRE0 Foot 2 AC
CONTROL PANEL PARTS
3- 1 DPWBFC045WRUZ Control unit 1 BB
3- 2 FPNLCB485WRKZ Panel frame with key unit 1 AY
3- 2-1 HPNLCB607WRFZ Control panel 1 AN
3- 2-2 PSHEPA723WREZ Key sheet 1 AM
3- 3 PPACGA175WREZ Packing 1 AF
OVEN PARTS
4- 1 PHOK-A117WRPZ Latch hook 1 AH
4- 2 PDUC-A740WRWZ Air intake duct 1 AD
4- 3 LBNDKA132WRP0 H.V. Capacitor holder 1 AD
4- 4 PDUC-A736WRPZ Magnetron air duct 1 AF
4- 5 PDUC-A743WRPZ Exhaust duct 1 AD
4- 6 PCUSUA541WRPZ Cushion 1 AC
4- 7 PDUC-A745WRWZ Fan duct 1 AE
4- 8 NFANJA029WRE0 Fan blade 1 AL
4- 9 PCUSUA540WRPZ Cushion 1 AC
4-10 PDUC-A752WRFZ Top air separator 1 AD
4-11 ************* Oven cavity (Not replaceable part) 1--
4-12 PCOVPA359WREZ Waveguide cover 1 AD
4-13 GLEGPA078WRFZ Leg (Left) 1 AE
4-14 GLEGPA079WRFZ Leg (Right) 1 AE
4-15 PDUC-A746WRFZ Air separator 1 AE
4-16 PSKR-A367WRFZ Barrier 1 AE
4-17 PCUSGA541WRPZ Cushion 2 AC
4-18 PPACGA097WRE0 O-ring 1 AG
4-19 PCUSUA542WRPZ Cushion 1 AC
4-20 PCUSGA543WRPZ Cushion 1 AC
4-21 PCUSUA543WRPZ Cushion 1 AC
4-22 PCUSUA544WRPZ Cushion 1 AC
4-23 LANGTA369WRPZ Chassis support 1 AF
4-24 PDUC-A753WRPZ Air duct 1 AE
4-25 LANGTA370WRPZ Support angle 1 AD
4-26 PCUSGA544WRPZ Cushion 1 AE
4-27 PCUSUA212WRP0 Cushion 1 AB
4-28 PCUSUA545WRPZ Cushion 1 AC
4-29 PCUSUA546WRPZ Cushion 1 AC
4-30 PSPAKA006WREZ Spacer 1 AE
4-31 PCUSUA452WRP0 Cushion 1 AB
4-32 PSPAKA008WREZ Spacer 1 AC
4-33 PSPAKA007WREZ Spacer 1 AC
4-34 LX-WZA053WREZ Special washer 1 AC
4-35 PSPAKA005WREZ Spacer 1 AC
4-36 PSPAKA004WREZ Spacer 1 AC
Rerer to "POSTION OF SPACERS" on page 9
