PARTS LIST
Note: The parts marked “
∆∆
∆∆
∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V. "§" MARK: PARTS DELIVERY SECTION.
ELECTRIC PARTS
1- 1 FH-DZB017MRY0 M High voltage rectifier assembly 1 AM
1- 2 RC-QZB234MRE0 M High voltage capacitor 1 AR
1- 3 QFS-TA013WRE0 M Temperature fuse 150½C 1 AG
1- 4 RHET-A174WRE0 M Convection heater 1 AZ
1- 5 RMOTDA211WRE0 M Turntable motor 1 AQ
1- 6 RMOTDA214WRE0 M Stirrer motor 1 AQ
1- 7 RTHM-B044MRE0 M Thermal cut-out N.O. 60½C 2 AG
1- 8 RTRN-B070MRE0 M Power transformer 1 BF
1- 9 RV-MZA255WRE0 M Magnetron 1 BE
1-10 QFSHDB003MRE0 M Fuse holder 1 AD
1-11 QSW-MA110WRE0 M Secondary interlock, door sensing and damper switches 3 AE
1-12 FFS-BA016/KIT M Monitor switch with fuse assembly 1 AF
1-13 FACCDB011MRE0 M Power supply cord 1 AP
1-14 QSOCLB006MRE0 M Hood lamp socket 2 AE
1-15 FH-HZA053WRE0 M Thermistor 1 AP
1-16 QSOCLB006MRE0 M Oven lamp socket 1 AE
1-17 FMOTEA362WRK0 M Hood fan motor 1 BM
1-18 RMOTEA343WRE0 M Convection motor 1 AX
1-19 RMOTEA344WRE0 M Fan motor 1 AW
1-20 RLMPTA068WRE0 M Hood lamp and oven lamp 3 AG
1-21 FDTCTA217WRK0 M AH sensor 1 AW
1-22 RMOTDA217WRE0 M Damper motor 1 AP
1-23 RR-WZA031WRE0 M Noise resistor 1 AK
CABINET PARTS
2- 1 PFIL-B002MRE0 M Grease filter 2 AF
2- 2 PDIF-B032MRF0 M Hood exhaust louver [R-1870] 1 AV
2- 2 PDIF-B033MRF0 M Hood exhaust louver [R-1871] 1 AV
2- 3 GDAI-B052MRP0 M Base plate right 1 AL
2- 4 GDAI-B039MRP0 M Base plate left 1 AH
2- 5 GCABUB106MRP0 M Outer case cabinet [R-1870] 1 BC
2- 5 GCABUB107MRP0 M Outer case cabinet [R-1871] 1 BC
2- 6 TMAPCB056MRR0 M Schematic diagram 1 AB
2- 7 FANGKB009MRY0 M Hood lamp glass assembly [R-1870] 1 AN
2- 7 FANGKB010MRY0 M Hood lamp glass assembly [R-1871] 1 AM
2-7-1 LANGQB033MRP0 M Hood lamp glass angle [R-1870] 1 AG
2-7-1 LANGQB020MRP0 M Hood lamp glass angle [R-1871] 1 AG
2-7-2 PGLSPB004MRE0 M Hood lamp glass 1 AH
2- 8 PCOVPB030MRT0A M Base cover [R-1870] 1 AX
2- 8 PCOVPB031MRT0 M Base cover [R-1871] 1 AX
2- 9 HDECQB030MRF0 M Sash left [R-1870] 1 AL
2- 9 HDECQB031MRF0 M Sash left [R-1871] 1 AL
2-10 LSTY-B010MRP0 M Rear stay 1 AG
CONTROL PANEL PARTS
3- 1 DPWBFB061MRU0 M Control unit 1 BQ
3- 1A QCNCMA227DRE0 J 3-pin connector CN-A 1 AC
3- 1B QCNCMA230DRE0 J 4-pin connector CN-B 1 AC
3- 1C QCNCMA234DRE0 J 5-pin connector CN-C 1 AC
3- 1D QCNCMA267DRE0 J 6-pin connector CN-E 1 AC
3- 1E QCNCMA237DRE0 J 3-pin connector CN-F 1 AD
3- 1F QCNCWA030DRE0 J 12-pin connector CN-G 1 AE
3- 1G RV-KXB003MRE0 M Fluorescent display tube 1 AV
3- 1H PTPEHB010MRE0 M Tape 2mm 1 AB
C1 RC-KZA087DRE0 J Capacitor 0.1 uF 50V 1 AB
C2 VCEAB31VW108M J Capacitor 1000 uF 35V 1 AF
C3 RC-KZA087DRE0 J Capacitor 0.1 uF 50V 1 AB
C4,C2 VCEAB31VW106M J Capacitor 10 uF 35V 2 AB
C6 VCEAB31VW106M J Capacitor 10 uF 35V 1 AB
C7-8 VCKYD11CY103N J Capacitor 0.01 uF 16V 2 AH
C9-10 RC-KZA087DRE0 J Capacitor 0.1 uF 50V 2 AB
C20 VCEAB31VW106M J Capacitor 10 uF 35V 1 AB
C21 VCEAB31HW104M J Capacitor 0.1 uF 50V 1 AM
C30,C5 VCKYD11CY103N J Capacitor 0.01 uF 16V 2 AH
C50,C11 VCKYD11CY103N J Capacitor 0.01 uF 16V 2 AH
C60 VCKYD11CY103N J Capacitor 0.01 uF 16V 1 AH
C70-74 VCKYD11HB331K J Capacitor 330 pF 50V 5 AA
C65 VCEAB31CW107M J Capacitor 100 µF 16v 1 AF
C100 RC-QZB014MRE0 M Capacitor 7 uF 230V 1 AM
CF1 RCRS-A010DRE0 J Ceramic resonator (CST4.00MGW) 1 AD
