31
R-201FK/W
R-203FW
R-205FW
R-206FW
∆
∆
∆
∆
∆
∆
REF. NO. PART NO. DESCRIPTION Q'TY CODE
CABINET PARTS
2- 1 GCABUA828WRPZ Outer case cabinet [R-201FK] 1 BD
2- 1 GCABUA817WRPZ Outer case cabinet [R-201FW][R-203FW][R-205FW][R-206FW] 1 BD
2- 2 GLEGPA074WRE0 Foot 2 AC
CONTROL PANEL PARTS
3- 1 FPNLCB636WRKZ Control panel frame with key unit [R-201FK] 1 BA
3- 1 FPNLCB623WRKZ Control panel frame with key unit [R-201FW] 1 BA
3- 1 FPNLCB622WRKZ Control panel frame with key unit [R-203FW] 1 BA
3- 1 FPNLCB635WRKZ Control panel frame with key unit [R-205FW] 1 BA
3- 1 FPNLCB634WRKZ Control panel frame with key unit [R-206FW] 1 BA
3- 1-1 PSHEPA823WREZ Graphic sheet [R-201FK] 1 AV
3- 1-1 PSHEPA802WREZ Graphic sheet [R-201FW] 1 AV
3- 1-1 PSHEPA801WREZ Graphic sheet [R-203FW] 1 AX
3- 1-1 PSHEPA822WREZ Graphic sheet [R-205FW] 1 AV
3- 1-1 PSHEPA821WREZ Graphic sheet [R-206FW] 1 AX
3- 1-2 QSW-KA014DRZZ Membrane switch 1 AQ
3- 2 JBTN-B175WRFZ Open button [R-201FK] 1 AG
3- 2 JBTN-B165WRFZ Open button [R-201FW] [R-203FW] [R-205FW] [R-206FW] 1 AH
3- 3 MSPRCA050WRE0 Open button spring 1 AB
3- 4 DPWBFC247WRUZ Control unit 1 BE
3- 5 QCNC-A014WRZZ Rubber connector 1 AE
3- 6 RLCDSA105DRZZ Liquid crystal display 1 AQ
3- 7 XEPSD30P08XS0 Screw; 3mm x 8mm 3 AA
OVENPARTS
4- 1 PHOK-A120WRFZ Latch hook 1 AH
4- 2 LBNDKA038WRP0 Capacitor holder 1 AF
4- 3 NFANJA029WRE0 Fan blade 1 AK
4- 4 PDUC-A788WRWZ Fan duct 1 AR
4- 5 ************* Oven cavity (Not replaceable part) 1--
4- 6 GCOVHA425WRPZ Turntable motor cover 1 AK
4- 7 MLEVPA241WRFZ Switch lever 1 AG
4- 8 PCOVPA276WRE0 Waveguide cover 1 AM
4- 9 PCUSUA237WRP0 Cushion 2 AF
4-10 PPACGA176WREZ TTM packing 1 AC
4-11 PCUSUA278WRP0 Cushion 1 AB
4-12 PCUSGA568WREZ Cushion 1 AC
DOORPARTS
5- 1 FDORFA348WRTZ Door panel assembly 1 BC
5- 2 GWAKPA854WRRZ Door frame [R-201FK] 1 AW
5- 2 GWAKPA836WRRZ Door frame [R-201FW][R-203FW][R-205FW][R-206FW] 1 AW
5- 3 HPNL-A764WREZ Door screen [R-201FK][R-201FW] 1 AP
5- 3 HPNL-A773WRRZ Door screen [R-203FW][R-205FW][R-206FW] 1 AQ
5- 4 LSTPPA205WRFZ Latch head 1 AF
5- 5 MSPRTA187WRE0 Spring 1 AC
5- 6 PSHEPA782WREZ Sealer film 1 AG
5- 7 GCOVHA424WRFZ Choke cover 1 AK
MISCELLANEOUS
6- 1 NTNT-A034WRF0 Turntable 1 AM
6- 2 FROLPA099WRKZ Turntable support 1 AP
6- 3 TCAUAA258WRRZ Monitor caution 1 AC
6- 4 TCAUAA268WRRZ DHHS caution label 1 AF
6- 5 TINSEA929WRRZ Instruction book 1 AM
6- 6 FW-VZB837WREZ Main wire harness 1 AR
SCREWS,NUTS AND WASHERS
7- 1 XHPSD40P08K00 screw : 4 mm x 8 mm 2 AC
7- 2 XHTSD40P08RV0 Screw : 4mm x 8mm 4 AA
7- 3 LX-CZA070WRE0 Special screw (Torx tamper pfoof screw) 2 AC
7- 4 LX-CZ0052WRE0 Special screw 2 AA
7- 5 LX-EZA042WRE0 Special screw 2 AB
7- 6 XHPSD30P06000 Screw : 3mm x 6mm 1 AA
7- 7 XHPSD40P08000 Screw : 4mm x 8mm 3 AA
7- 8 XHTSD40P12RV0 Screw : 4mm x 12mm 1 AA
7- 9 XOTSF40P08000 Screw : 4mm x 8mm [R-201FK] 2 AA
7- 9 XOTSE40P08000 Screw : 4mm x 8mm [R-201FW][R-203FW][R-205FW][R-206FW] 2AA
7- 10 XOTSD40P08000 Screw : 4mm x 8mm 7 AA
7- 11 XCPSD40P06000 Screw : 4mm x 6mm 1 AA
