Sharp R-22AM Service Manual

46
R-22AM
R-23AM
R-23AT
∆
∆
∆
∆
PARTS LIST
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
*
*
*
∆
*
*
*
*
ELECTRIC PARTS
BM FMOTEA309WRK0 Blower motor 1 BH
C1, C2 RC-QZA264WRE0 High voltage capacitor 2 AY
F1 QFS-CA017WRE0 Weak point A017 1 AF
F2 QFS-CA007WRE0 Fuse 6.3A 1 AD
F3, F4 QFS-CA010WRE0 Fuse M8A 2 AE
F5, F6 QFS-IA002WRE0 High voltage fuse 0.75A/ 5kV [R-23AM/23AT] 2 AQ
F5, F6 QFS-IA004WRE0 High voltage fuse 0.6A/ 5kV [R-22AM] 2 AK
MG1, MG2 RV-MZA300WRE0 Magnetron 2 BG
OL RLMPTA028WRE0 Oven lamp 1 AK
R1 RR-WZA020WRE0 Monitor resistor 4.3 ohm 20W 1 AF
SM RMOTDA238WRZZ Stirrer motor 2 AR
SW1 QSW-MA095WRE0 1st. latch switch 1 AF
SW2 QSW-MA095WRE0 2nd. latch switch 1 AF
SW3 QSW-MA095WRE0 3rd. latch switch 1 AF
SW4 QSW-MA086WRE0 Monitor switch 1 AF
SW5 QSW-MA085WRE0 Stop switch 1 AF
T1, T2 RTRN-A599WRE0 High voltage transformer [R-23AM/R-23AT] 2 BM
T1, T2 RTRN-A600WRE0 High voltage transformer [R-22AM] 2 BN
TF1, TF2 QFS-TA014WRE0 Temperature fuse 150˚C (MG.) 2 AG
TF3, TF4 QFS-TA015WRE0 Temperature fuse 120˚C (OVEN, BM.) 2 AG
1- 1 FH-HZA064WRE0 Oven thermistor (2) 1 AV
1- 2 QSOCLA024WRE0 Oven lamp socket 1 AH
1- 3 FW-QZA117WRK0 High voltage rectifier assembly 1 AU
1- 4 FPWBFA335WRE0 Noise filter 1 AX
1- 5 QFSHDA019WRE0 Fuse holder 3 AH
1- 6 FACCVA013WRK0 Power supply cord 1 BG
1- 7 FH-HZA070WRE0 Oven thermistor (1) & Magnetron thermistor 2 AM
CABINET PARTS
2- 1 FDAI-A183WRW0 Base plate assembly 1 BC
2- 2 PSHEGA006WRE0 Rubber sheet A 2 AF
2- 3 PSHEGA007WRE0 Rubber sheet B 2 AE
2- 4 GCOVAA283WRW0 Rear cabinet 1 AX
2- 5 FFTASA064WRY0 Oven lamp access cover assembly 1 AN
2-5-1 PCUSU0407WRP0 Cushion 1 AA
2-5-2 PREFHA059WRP0 Reflector 1 AF
2- 6 GCABUA523WRP0 Outer case cabinet 1 BA
2- 7 FFPF-A016WRK0 Vibration-proof sheet 1 AU
2- 8 PZETEA079WRP0 Insulation sheet 2 AC
OVEN PARTS
4- 1 PZETEA047WRP0 Switch insulator 1 AC
4- 2 FDUC-A345WRY0 Exhaust duct assembly 1 AP
4- 3 FOVN-A444WRY0 Oven cavity 1 BS
4- 4 PFILWA053WRP0 Oven light screen (Inside) 1 AE
4- 5 MLEVPA153WRF0 Switch lever A 1 AC
4- 6 MLEVPA154WRF0 Switch lever B 1 AC
4- 7 MLEVPA155WRF0 Switch lever C 1 AC
4- 8 MSPRCA075WRE0 Switch spring A 1 AB
4- 9 MSPRCA076WRE0 Switch spring B 2 AB
4-10 PHOK-A081WRF0 Latch hook 1 AP
4-11 MHNG-A216WRM0 Lower oven hinge 1 AG
4-12 PCUSUA442WRP0 Cushion 1 AF
4-13 PCUSU0407WRP0 Cushion 1 AA
4-14 FGLSPA063WRY0 Ceramic shelf 1 BF
4-15 FPLT-A008WRY0 Stirrer antenna upper assembly 1 AV
4-16 FPLT-A009WRY0 Stirrer antenna lower assembly 1 AV
4-17 LANGKA762WRP0 Partition angle R 1 AE
4-18 LANGQA370WRP0 Oven lamp mounting plate 1 AD
4-19 LBNDKA068WRP0 Capacitor holder 1 AD
4-20 PGIDHA054WRW0 Water-proof cover 1 AF
4-21 NSFTPA031WRF0 Antenna motor shaft 2 AH
4-22 PCUSUA451WRP0 Cushion 1 AB
4-23 PCUSUA417WRP0 Cushion 1 AB
4-24 MHNG-A215WRM0 Upper oven hinge 1 AG
4-25 PCUSUA413WRP0 Cushion 1 AG
4-26 PCUSUA415WRP0 Cushion 3 AC
4-27 PDUC-A729WRF0 Air duct 1 AL
4-28 PDUC-A564WRW0 Mg exhaust duct 1 AP
4-29 PCUSUA414WRP0 Cushion 1 AD
4-30 LANGKA679WRM0 Fixing angle S 1 AD
4-31 HDECQA147WRM0 Corner cap right 1 AE
4-32 LANGFA195WRP0 Chassis support 1 AG
