3
2
OVEN AND ACCESSORIES
1 Control panel
2 Oven lamp
3 Door opening handle
4 Waveguide cover
5 Seal packing
6 Oven cavity
7 Door seals and sealing surfaces
8 Menu label
9 Ventilation openings
10 Outer cabinet
11 Power cord
9
11
ACCESSORIES:
Check to make sure the following accessories are
provided:
(12) Turntable (13) Roller stay (14) Seal packing
• Place the roller stay in the seal packing on the
floor of the cavity.
• Then place the turntable on the roller stay.
• To avoid turntable damage, ensure dishes or
containers are lifted clear of the turntable rim when
removing them from the oven.
NOTE: When you order accessories, please mention
two items: part name and model name to your dealer
or SHARP authorised service agent.
12
13
14
1
2
7 6 5 4
8
10
