Sharp R-290H Service Manual

R-290H(S)
29
PARTS LIST
*
*
*
*
*
∆
*
*
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
∆
∆
∆
∆
∆
∆
ELECTRIC PARTS
1- 1 QACCAA048WRZZ Power supply cord 1 AS
1- 1 QACCAA045WRE0 Power supply cord (Interchangeable) 1 AT
1- 2 FPWBFA347WRKZ Noise filter 1 AX
1- 3 FH-DZA102WRKZ High voltage rectifier assy 1 AN
1- 3 FH-DZA088WRK0 High voltage rectifier assy (Interchangeable) 1 AP
1- 4 RC-QZA295WRZZ High voltage capacitor 1 AV
1- 4 RC-QZA218WRE0 High voltage capacitor (Interchangeable) for production use 1--
1- 5 QFS-CA027WRZZ Fuse T6.3A 1 AG
1- 6 QFS-IA004WRE0 High voltage fuse 0.6A 1 AK
1- 7 RMOTEA403WRZZ Fan motor 1 AZ
1- 7 RMOTEA340WRE0 Fan motor (Interchangeable) 1 AX
1- 7 RMOTEA389WRE0 Fan motor (Interchangeable) for production use 1--
1- 8 RV-MZA306WRZZ Magnetron 1 BL
1- 9 RLMPTA083WRZZ Oven lamp 1 AM
1-10 QSW-MA137WRE0 1st. latch switch/ 2nd. interlock relay control switch 2 AH
1-11 QSW-MA138WRE0 Monitor switch 1 AH
1-12 RTRN-A656WRZZ Power transformer 1 BH
1-13 QFS-TA038WRE0 Temperature fuse 120˚C (Oven) 1 AK
1-14 RMOTDA226WRE0 Turntable motor 1 AT
1-14 RMOTDA173WRE0 Turntable motor (Interchangeable) 1 AX
CABINET PARTS
2- 1 GCABUA864WRPZ Outer case cabinet 1 BD
2- 2 GLEGPA074WRE0 Foot 2 AC
2- 3 PCUSUA605WRPZ Cushion 1 AG
CONTROL PANEL PARTS
3- 1 FPNLCB696WRKZ Control panel frame with key unit 1 AZ
3- 1-1 PSHEPA870WRZZ Graphic sheet 1 AX
3- 1-2 QSW-KA026DRZZ Membrane switch 1 AQ
3- 1-3 GMADIA118WRRZ Display window 1 AL
3- 1-4 HDECQA236WRPZ Control panel decoration 1 AT
3- 2 FBTN-A146WRKZ Open button assembly 1 AS
3- 2-1 JBTN-B187WRFZ Open button 1 AH
3- 2-2 HDECQA239WRPZ Button decoration 1 AT
3- 3 MSPRCA050WRE0 Open button spring 1 AB
3- 4 DPWBFC244WRUZ Control unit 1 BF
3- 5 QCNC-A014WRZZ Rubber connector 1 AE
3- 6 RLCDSA106DRZZ Liquid crystal display 1 AQ
3- 7 XEPSD30P08XS0 Screw; 3mm x 8mm 3 AA
OVENPARTS
4- 1 PHOK-A122WRFZ Latch hook 1 AM
4- 2 LBNDKA038WRP0 Capacitor holder 1 AF
4- 3 NFANJA043WRE0 Fan blade 1 AK
4- 4 PDUC-A801WRWZ Fan duct 1 AR
4- 5 FOVN-A483WRTZ Oven cavity 1 BF
4- 6 GCOVHA425WRPZ Turntable motor cover 1 AK
4- 7 MLEVPA241WRFZ Switch lever 1 AG
4- 8 PCOVPA276WRE0 Waveguide cover 1 AM
4- 9 PCUSUA237WRP0 Cushion 2 AF
4-10 PPACGA176WREZ TTM packing 1 AC
4-11 PCUSUA278WRP0 Cushion 1 AB
4-12 PCUSGA389WRP0 Cushion 1 AG
4-13 PCUSGA568WREZ Cushion 1 AC
4-14 PCUSUA461WRP0 Cushion 1 AB
DOORPARTS
5- 1 FDORFA348WRTZ Door panel assembly 1 BC
5- 2 FWAKPA373WRKZ Door frame assembly 1 AY
5- 2-1 GWAKPA871WRFZ Door frame 1 AW
5- 2-2 HDECQA237WRRZ Door decoration U 1 AU
5- 2-3 HDECQA238WRPZ Door decoration L 1 AT
5- 3 HPNL-A785WRRZ Door screen 1 AS
5- 4 LSTPPA205WRFZ Latch head 1 AF
5- 5 MSPRTA187WRE0 Spring 1 AC
5- 6 PSHEPA782WREZ Sealer film 1 AG
5- 7 GCOVHA424WRFZ Choke cover 1 AK
MISCELLANEOUS
6- 1 NTNT-A094WRE0 Turntable 1 AN
