Figure S-1. Pictorial Diagram
HIGH VOLTAGE
CAPACITOR
H.V. RECTIFIER
POWER SUPPLY
CORD 120V 60Hz
HIGH VOLTAGE COMPONENTS
MAGNETRON
COM.
MONITOR
SWITCH
COM.
N.O.
N.C.
DOOR
SENSING
SWITCH
SECONDARY
INTERLOCK
SWITCH
TURNTABLE
MOTOR
POWER
TRANSFORMER
COM.
NO
NOTE:
The neutral (WHT) wire must be
connected to the terminal with "N"
mark on the power supply cord.
GRY
W
H
T
WHT
GRY
RED
GRY
GRY
R
E
D
P
N
K
B
L
K
R
E
D
GRN
GRY
GRY
GRN
BLK
GRY
WHT
GRY
RED
RED
BLK
PNK
GRY
C/T FUSE
FAN MOTOR
TEMPERATURE
FUSE (OVEN)
BLK
WHT
2
1
WHT
WHT
WHT
WHT
RED
RY1
PRIMARY
INTERLOCK
RELAY
CN-B
CN-B
T1
1
2
N.O.
COM.
RY2
N.O.
COM.
CONTROL UNIT
H
N
NOTE:
The grounding conductor of
the power supply cord has
been grounded by power
supply cord fixing screw.
The screw must allways be
kept tight.
GRY
OVEN LAMP
PNK
RED
RED
PNK
