Sharp R-310BK User Manual

32
R-310BK
R-310BW
*
*
∆
*
∆
*
*
∆
PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
ELECTRIC PARTS
1- 1 QSW-MA110WRE0 2nd interlock switch / door sensing switch 2 AK
1- 2 QFSHDA009WRE0 Fuse holder 1 AH
1- 3 FFS-BA021WRK0 Monitor fuse and monitor switch assembly 1 AL
1- 4 RTHM-A078WRE0 Thermal cut-out 125 deg. 1 AL
1- 5 FACCDA077WRE0 Power supply cord 1 AU
1- 6 FH-DZA083WRK0 High voltage rectifier assembly 1 AQ
1- 7 RC-QZA236WRE0 High voltage capacitor 1 AX
1- 8 RV-MZA267WRE0 Magnetron 1 BL
1- 8 RV-MZA197WRE0 Magnetron (Interchangeable) 1 BN
1- 9 RMOTEA355WRE0 Fan motor 1 AU
1- 9 RMOTEA338WRE0 Fan motor (Interchangeable) 1 AV
1-10 QSOCLA021WRE0 Oven lamp socket 1 AH
1-11 RLMPTA030WRE0 Oven lamp 1 AF
1-12 RMOTDA161WRE0 Turntable motor 1 AU
1-13 RTHM-A048WRE0 Thermal cut-out 170 deg. 1 AH
1-14 RTRN-A569WRE0 Power transformer 1 BP
CABINET PARTS
2- 1 GCABUA649WRP0 Outer case cabinet [R-310BW] 1 AZ
2- 1 GCABUA631WRP0 Outer case cabinet [R-310BK] 1 BB
2- 2 GDAI-A261WRW0 Bottom left plate 1 AP
2- 3 GDAI-A286WRW0 Bottom right plate 1 AN
2- 4 GLEGPA019WRE0 Foot 2 AD
2- 5 GLEGPA067WRF0 Leg 1 AE
CONTROL PANEL PARTS
3- 1 CPWBFA766WRK0 Power unit 1 BD
3- 1A QCNCMA446DRE0 2-pin connector (CN-A) 1 AC
3- 1B QCNCMA422DRE0 9-pin connector (CN-C) 1 AF
3- 1C FW-VZA195DRE0 Switch harness A (SH-A) 1 AD
3- 1D FW-VZA197DRE0 Switch harness B (SH-B) 1 AD
3- 1E FW-VZA196DRE0 Lead wire harness (WH-1) 1 AD
3- 1F LHLD-A171WRF0 LED holder 1 AE
C1 RC-KZA087DRE0 Capacitor 0.1uF 50V 1 AB
C2 VCEAB31VW108M Capacitor 1000uF 35V 1 AF
C5 VCEAB31VW106M Capacitor 10uF 35V 1 AA
D1-4 VHD11ES1///-1 Diode (11ES1) 4 AB
D5-8 VHD1SS270A/-1 Diode (1SS270ATA) 4 AA
LD1-5 VHPSLZ381A9-3 Light emitting diode 5 AC
Q2 VS2SB1238//-3 Transistor (2SB1238) 1 AA
Q3 VSDTD143ES/-3 Transistor (DTD143ES) 1 AC
R2-3 VRD-B12HF821J Resistor 820 ohm 1/2W 2 AA
R4 VRD-B12EF270J Resistor 27 ohm 1/4W 1 AA
R5 VRD-B12EF472J Resistor 4.7k ohm 1/4W 1 AA
R6 VRD-B12EF332J Resistor 3.3k ohm 1/4W 1 AA
RY1 RRLY-A098DRE0 Relay (OMIF-S-124LM) 1 AL
RY2 RRLY-A081DRE0 Relay (VRB24) 1 AL
SP1 RALM-A014DRE0 Buzzer (PKM22EPT-THAI) 1 AG
T1 RTRNPA111DRE0 Transformer 1 AP
VRS1 RH-VZA032DRE0 Varistor (10G471K) 1 AE
3- 2 DPWBFB796WRK0 CPU unit 1 AY
3- 3 FPNLCB277WRK0 Control panel frame with key unit [R-310BW] 1 BC
3- 3 FPNLCB281WRK0 Control panel frame with key unit [R-310BK] 1 BC
3- 3- 1 FUNTKA792WRE0 Key unit [R-310BW] 1 AY
3- 3- 1 FUNTKA795WRE0 Key unit [R-310BK] 1 AZ
3- 4 PSHEPA588WRE0 LED sheet 1 AM
3- 5 JBTN-B028WRF0 Open button [R-310BK] 1 AG
3- 5 JBTN-B029WRF0 Open button [R-310BW] 1 AB
3- 6 MSPRCA050WRE0 Open button spring 1 AB
3- 7 XEPSD30P08XS0 Screw: 3mm x 8mm 4 AA
OVEN PARTS
4- 1 PCUSUA376WRP0 Cushion 1 AG
4- 2 PPACGA084WRF0 TTM packing 1 AF
4- 3 PHOK-A106WRF0 Latch hook 1 AL
4- 4 LBNDKA099WRW0 Capacitor holder 1 AD
4- 5 NFANJA029WRE0 Fan blade 1 AL
