Sharp R-350Y User Manual

R-350Y(S)
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[1] OVEN PART
1-1 QSW-MA147WRZZ AG 1st.latch/ 2nd.interlock relay control switch (Micro switch a)
1-1 QSW-MA085WRE0 AF 1st.latch/ 2nd.interlock relay control switch (Micro switch a Interchangeable)
1-1 QSW-MA137WRE0 AH 1st.latch/ 2nd.interlock relay control switch (Micro switch a Interchangeable)
1-2 QSW-MA148WRZZ AF Monitor switch (Micro switch b)
1-2 QSW-MA086WRE0 AF Monitor switch (Micro switch b Interchangeable)
1-2 QSW-MA138WRE0 AH Monitor switch (Micro switch b Interchangeable)
1-3 QACC-A178WRZZ AQ Power supply cord
1-3 QACC-A156WRZZ AQ Power supply cord (Interchangeable)
1-3 QACC-A139WRZZ AQ Power supply cord (Interchangeable)
1-3 QACC-A180WRZZ AQ Power supply cord (Interchangeable)
1-4 DPWBFC625WRKZ BQ Inverter unit
1-6 RMOTEA450WRZZ AV Fan motor
1-6 RMOTEA405WRZZ AX Fan motor (Interchangeable)
1-6 RMOTEA450WRZZ AV Fan motor (Interchangeable)
1-6 RMOTEA475WRZZ AX Fan motor (Interchangeable)
1-7 QFS-TA014WRE0 AG Temperature fuse 150A(oven) (Temp. Fuse 150H)
1-8 RLMPTA088WRZZ AN Oven lamp
1-8 RLMPTA083WRZZ AM Oven lamp (Interchangeable)
1-8 RLMPTA101WRZZ AM Oven lamp (Interchangeable)
1-9 RMOTDA302WRZZ AN Turntable motor
1-9 RMOTDA253WRZZ AV Turntable motor (Interchangeable)
1-9 RMOTDA289WRZZ AQ Turntable motor (Interchangeable)
1-9 RMOTDA173WRE0 AX Turntable motor (Interchangeable)
1-9 RMOTDA299WRZZ BE Turntable motor (Interchangeable)
* 1-11 RV-MZA381WRZZ BG Magnetron
1-12 FPWBFA461WRKZ AT Noise filter unit
1-13 QFS-CA026WRZZ AH Fuse f10a
1-15 FDTCTA230WRKZ AX Humidity sensor
2-1 GCABUA935WRPZ BD Outer case cabinet [R-350Y(S)]
2-1 GCABUA883WRPZ BF Outer case cabinet [R-350Y(W)]
2-2 GDAI-A489WRWZ AS Bottom plate
2-3 GLEGPA074WRE0 AC Leg
4-1 PHOK-A131WRFZ AL Latch hook
4-2 LANGQA841WRPZ AH Inverter angle
4-3 NFANJA053WRFZ AG Fan blade
4-4 FOVN-A693WRTZ Oven cavity assy
4-5 MLEVPA233WRF0 AG Switch lever
4-7 FCOVPA083WRKZ AF Wg cover assy
4-8 PDUC-A833WRPZ AM Air duct
4-9 PDUC-A854WRPZ AL Fan duct
4-10 PPACGA176WREZ AC Ttm packing
4-11 PDUC-B224WRPZ AG Lower fan duct
4-12 PCUSUA278WRP0 AB Mg cushion
4-14 PCUSGA614WRPZ AE Cushion
4-15 PCUSGA615WRPZ AE Cushion
4-16 MROD-A019WREZ AN Chassis support
4-17 PCUSUA313WRP0 AF Cushion
4-18 PCUSGA620WRPZ AF Cushion
4-19 PSPAJA007WRFZ AF Spacer
4-23 PDUC-A842WRPZ AP Sensor duct
4-24 PCUSGA388WRP0 AK Rubber cushion
4-25 PCUSUA212WRP0 AB Cushion
6-1 FROLPA101WRKZ AR Roller assy
6-2 NTNT-A117WREZ AS Turntable
6-3 TCAUHA343WRRZ AF Micro caution
6-5 TLABMB405WRRZ AF Menu label
7-1 XHPS740P08K00 AB Screw : 4mm x 8mm
7-2 XOTS740P12RV0 AD Screw : 4mm x 12mm
7-3 LX-CZA073WRE0 AC Special screw
7-4 LX-CZ0052WRE0 AA Special screw
7-5 XOTS740P08000 AA Screw : 4mm x 8mm
7-6 XETS740P10000 AA Screw : 4mm x 10mm
7-7 XHPS740P08000 AB Screw : 4mm x 8mm
7-8 XHTS740P08RV0 AG Screw : 4mm x 8mm
7-9 XHTS740P08000 AC Screw : 4mm x 8mm
7-10 XOTS740P08000 AA Screw : 4mm x 8mm
7-11 XHPS730P06000 AB Screw : 3mm x 6mm
ELECTRIC PARTS
CABINET PARTS
OVEN PARTS
MISCELLANEOUS
SCREWS
