2
OVEN AND ACCESSORIES
1 Door
2 Door hinges
3 Oven lamp
4 Waveguide cover
5 Control panel
6 Coupling
7 Door lock openings
8 Oven cavity
9 Door seals and sealing surfaces
10 Door safety latches
11 Door opening handle
12 Ventilation openings
13 Outer cabinet
14 Power supply cord
15
16
17
1
11
2
8
7
6
5
4
3
9
10
12
13
14
OVEN
ACCESSORIES:
Check to make sure the following accessories are
provided:
(15) Turntable (16) Roller stay (17) Coupling
Place the turntable support in the centre of the oven
floor so that it can freely rotate around the coupling.
Place the turntable onto the turntable support so that it
locates firmly into the coupling.
To avoid turntable damage, ensure dishes or
containers are lifted clear of the turntable rim when
removing them from the oven.
NOTE: When you order accessories, please mention
two items: part name and model name to your dealer
or SHARP authorised service agent.
