R-3S56
PARTS LIST
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
*
*
*
*
∆
ELECTRIC PARTS
1- 1 FH-DZA051WRK0 High voltage rectifier assembly 1 AN
1- 2 QACC-A034WRE0 Power supply cord 1 AW
1- 3 QSOCLA011WRE0 Oven lamp socket 1 AH
1- 4 QFSHDA019WRE0 Fuse holder 1 AH
1- 5 RC-QZA126WRE0 High voltage capacitor 1 AX
1- 6 QFS-C0019WRE0 Fuse M6.3A 1 AC
1- 7 RMOTEA265WRE0 Fan motor 1 AZ
1- 8 RV-MZA195WRE0 Magnetron 1 BM
1- 9 RLMPTA028WRE0 Oven lamp 1 AK
1- 10 RR-WZA022WRE0 Monitor resistor 0.8 OHM 20W 1 AK
1- 11 QSW-MA110WRE0 1st. latch switch 1 AK
1- 12 QSW-MA110WRE0 2nd. latch switch 1 AK
1- 13 QSW-MA111WRE0 Monitor switch 1 AK
1- 14 RTRN-A376WRE0 Power transformer 1 BS
1- 15 RTHM-A079WRE0 Thermal cut-out 95° C1AL
1- 16 QFS-TA013WRE0 Temperature fuse 150° C1AG
1- 17 QSW-MA110WRE0 Stop switch 1 AK
1- 18 RMOTDA173WRE0 Turntable motor 1 AX
1- 19 QFS-TA013WRE0 Temperature fuse 150° C1AG
1- 20 QPLGAA018WRE0 AC plug 1 AL
CABINET PARTS
2- 1 GCABUA532WRP0 Outer case cabinet 1 AX
2- 2 GDAI-A236WRW0 Bottom plate L 1 AN
2- 3 GDAI-A237WRW0 Bottom plate R 1 AQ
2- 4 GLEGPA023WRE0 Foot 2 AB
CONTROL PANEL PARTS
3- 1 CPWBFA610WRK0 Control unit 1 BK
3- 1A QCNCMA234DRE0 3-pin connector (A) 1 AC
3- 1B QCNCMA275DRE0 2-pin connector (B) 1 AB
C1 VCEAB31CW477M Capacitor 470uF 16V 1 AB
C2 RC-KZA087DRE0 Capacitor 0.1uF 50V 1 AB
C3 VCEAB31CW476M Capacitor 47uF 16V 1 AA
C4 VCKYD11CY103N Capacitor 0.01uF 16V 1 AH
C5-6 VCEAB31VW107M Capacitor 100uF 35V 2 AB
C10 VCKYD11CY103N Capacitor 0.01uF 16V 1 AH
C20 VCTYF31HF103Z Capacitor 0.01uF 50V 1 AB
C50 VCKYD11CY103N Capacitor 0.01uF 16V 1 AH
C80 VCEAB31HW104M Capacitor 0.1uF 50V 1 AM
C81 VCEAB31VW106M Capacitor 10uF 35V 1 AB
CF1 RCRS-A012DRE0 Ceramic resonator (CST4.00MGW) 1 AD
D1 RSRCDA013DRE0 Diode bridge (S1NB10) 1 AG
D2-3 VHD11ES1///-1 Diode (11ES1) 2 AB
D50-51 VHD1SS270A/-1 Diode (1SS270A) 2 AA
D81-82 VHD1SS270A/-1 Diode (1SS270A) 2 AA
D91-93 VHD1SS270A/-1 Diode (1SS270A) 3 AA
IC1 RH-IZA588DRE0 LSI 1 AM
LED71-72 VHPSL3263H/-6 Light emitting diode (SL-3263H) 2 AR
Q1 RH-IZA401DRE0 Integrated circuit (LM7905CT) 1 AE
Q10 VSKRA101M//-3 Transistor (KRA101M) 1 AB
Q20 VSKRA101M//-3 Transistor (KRA101M) 1 AB
Q40 VSKRA101M//-3 Transistor (KRA101M) 1 AB
Q71-74 VSKRA222M//-3 Transistor (KRA222M) 4 AB
Q80 VSKRA101M//-3 Transistor (KRA101M) 1 AB
Q81 VSKRC243M//-3 Transistor (KRC243M) 1 AB
Q82 VSKRA223M//-3 Transistor (KRA223M) 1 AB
R2 VRD-B12EF104J Resistor 100k ohm 1/4W 1 AA
R10 VRD-B12EF153J Resistor 15k ohm 1/4W 1 AA
R20 VRD-B12EF153J Resistor 15k ohm 1/4W 1 AA
R40 VRD-B12EF332J Resistor 3.3k ohm 1/4W 1 AA
R50 VRD-B12EF101J Resistor 100 ohm 1/4W 1 AA
R51 VRD-B12EF512J Resistor 5.1k ohm 1/4W 1 AA
R71-78 VRD-B12EF151J Resistor 150 ohm 1/4W 8 AA
R80 VRD-B12EF471J Resistor 470 ohm 1/4W 1 AA
R81 VRD-B12EF153J Resistor 15k ohm 1/4W 1 AA
R91-93 VRD-B12EF104J Resistor 100k ohm 1/4W 3 AA
RY1 RRLY-A078DRE0 Relay (OJ-SH-118LM) 1 AG
RY2 RRLY-A083DRE0 Relay (OMIF-S-118LM) 1 AK
