33
R-409EW
R-410EK
R-410EW
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
PARTS LIST
Note: The parts marked “
∆∆
∆∆
∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V. "§" MARK: PARTS DELIVERY SECTION.
*
*
*
*
∆
∆
∆
∆
∆
∆
∆
ELECTRIC PARTS
1- 1 RC-QZB018MRE0 M High voltage capacitor 1 AQ
1- 2 FH-DZB008MRY0 M High voltage rectifier assembly (R-410EK/EW) 1 AM
1- 2 FH-DZB013MRY0 M High voltage rectifier assembly (R-409EW) 1 AM
1- 3 QSOCLB006MRE0 M Oven lamp socket 1 AE
1- 4 RLMPTA068WRE0 M Oven lamp 1 AE
1- 5 RMOTEA346WRE0 M Fan motor 1 AR
1- 6 QFSHDB003MRE0 M Fuse holder 1 AD
1- 7 FFS-BA016/KIT M
Monitor switch (V-16G-2C25) and fuse assembly (20A 250V AC) 1AF
1- 8 QSW-MA085WRE0 M
Secondary interlock switch and door sensing switch (V-5230Q) 2AE
1- 9 QFS-TA013WRE0 M Magnetron temperature fuse 150
O
C1AE
1-10 QFS-TA014WRE0 M Cavity temperature fuse 150
O
C1AF
1-11 RV-MZA255WRE0 M Magnetron (R-410EK/EW) 1 BE
1-11 RV-MZA303WRE0 M Magnetron (R-409EW) 1 BE
1-12 RMOTDA211WRE0 M Turntable motor 1 AL
1-13 RTRN-B064MRE0 M Power transformer (R-410EK/EW) 1 BA
1-13 RTRN-B065MRE0 M Power transformer (R-409EW) 1 BA
1-14 FACCDB003MRE0 M Power supply cord (R-410EK/EW) 1 AM
1-14 FACCDB001MRE0 M Power supply cord (R-409EW) 1 AM
CABINET PARTS
2- 1 GDAI-B057MRP0 M Base plate 1 BC
2- 2 GLEGPB004MRF0 M Foot 4 AB
2- 3 GCABUB092MRP0 M Outer case cabinet [R-410EK] 1 BC
2- 3 GCABUB093MRP0 M Outer case cabinet [R-410EW] & [R-409EW] 1 BC
CONTROL PANEL PARTS
3- 1 DPWBFB099MRK0 M Power Supply unit [R-409EW/R-410EK/EW] 1 AW
3- 1A QCNCMA275DRE0 J 2-pin connector (CN-A) 1 AB
3- 1B QCNCMA275DRE0 J 2-pin connector (CN-B) 1 AB
3- 1C FW-VZB169MRE0 M 9Pin wire harness (CN-C) 1 AM
C1 RC-EZA333DRE0 J Capacitor 2200 uF 25V 1 AE
D1 RSRCDA013DRE0 J Diode bridge (S1NB10) 1 AG
RY1-2 RRLY-A114DRE0 J Relay (DU12D1-1PR(M)) 2 AN
SP1 RALM-A014DRE0 J Buzzer (PKM22EPT) 1 AG
T1 RTRNPB013MRE0 M Transformer 1 AK
T1 RTRNPA110DRE0 J Transformer (Interchangeable) 1 AP
VRS1 RH-VZB002MRE0 M Varistor (470ND-10D) 1 AB
VRS1 RH-VZA032DRE0 J Varistor (10G471K) (Interchangeable) 1 AE
3- 2 DPWBFC163WRKZ M LSI unit [R-409EW/R-410EK/EW] 1 AX
3- 3 FPNLCB341/KIT M Control panel frame with key unit [R-410EK] 1 AV
3- 3 FPNLCB342/KIT M Control panel frame with key unit [R-410EW] 1 AV
3- 3 FPNLCB338/KIT M Control panel frame with key unit [R-409EW] 1 AV
3- 4 FUNTKB288/KIT M Key unit [R-410EK] 1 AL
3- 4 FUNTKB289/KIT M Key unit [R-410EW] 1 AL
3- 4 FUNTKB285/KIT M Key unit [R-409EW] 1 AL
3- 5 JBTN-B095MRF0 M Open button [R-410EW] 1 AE
3- 5 JBTN-B094MRF0 M Open button [R-410EK] 1 AE
3- 5 JBTN-B087MRF0 M Open button [R-409EW] 1 AE
3- 6 MSPRTA050WRE0 M Open button spring 1 AA
3- 7 PSHEPB023MRE0 M LED sheet 1 AR
3- 8 LHLD-B007MRF0 M LCD holder 1 AD
3- 9 XEPSD30P10XS0 M Screw; 3mm x 10mm 4 AA
OVEN PARTS
4- 1 LBNDKB007MRP0 M H.V. Capacitor band 1 AB
4- 2 LANGTB048MRP0 M Chassis support 1 AE
4- 3 PHOK-B018MRF0 M Latch hook 1 AF
4- 4 MLEVPB016MRF0 M Switch lever 1 AD
4- 5 PDUC-B104MRF0 M Magnetron duct 1 AG
4- 6 NFANPB006MRE0 M Fan blade 1 AC
4- 7 PDUC-B088MRF0 M Fan duct 1 AC
4- 8 ------------- M Oven cavity (Not a replaceable part) 1 --
4- 9 PCOVPB085MRP0 M Waveguide cover 1 AV
4-10 PPACGB014MRF0 M Turntable motor packing 1 AA
4-11 PCUSUB033MRP0 M Cushion 1 AA
