Sharp R-420CK User Manual

37
R-420CK
R-420CW
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
PARTS LIST
Note: The parts marked “Д may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V. "§" MARK: PARTS DELIVERY SECTION.
*
*
*
Ð
*
ELECTRIC PARTS
1- 1 RC-QZB018MRE0 M High voltage capacitor 1 AQ
1- 2 FH-DZB008MRY0 M High voltage rectifier assembly 1 AM
1- 3 QSOCLB006MRE0 M Oven lamp socket 1 AE
1- 4 RLMPTA068WRE0 M Oven lamp 1 AE
1- 5 RMOTEA346WRE0 M Fan motor 1 AR
1- 6 QFSHDB003MRE0 M Fuse holder 1 AD
1- 7 FFS-BA016/KIT M
Monitor switch (V-16G-2C25) and fuse assembly (20A 250V AC) 1AF
1- 8 QSW-MA085WRE0 M
Secondary interlock switch and door sensing switch (V-16G-3C25) 2AE
1- 9 QFS-TA013WRE0 M Magnetron temperature fuse 150
O
C 1AE
1-10 QFS-TA014WRE0 M Cavity temperature fuse 150
O
C 1AF
1-11 RV-MZA255WRE0 M Magnetron 1 BE
1-12 RMOTDA211/KIT M Turntable motor 1 AL
1-13 RTRN-B061MRE0 M Power transformer 1 BD
1-14 FACCDB003WRE0 M Power supply cord 1 AM
1-15 FDTCTA198WRK0 M AH sensor 1 AN
CABINET PARTS
2- 1 GDAI-B053MRP0 M Base plate 1 AR
2- 2 GLEGPB004MRF0 M Foot 4AB
2- 3 GCABUB064MRP0 M Outer case cabinet [R-420CK] 1 AW
2- 3 GCABUB088MRP0 M Outer case cabinet [R-420CW] 1 AV
CONTROL PANEL PARTS
3- 1 CPWBFB031MRU0 M Control unit 1 BL
3- 1A QCNCMA446DRE0 J 2-pin connector (CN-A) 1 AC
3- 1B QCNCMA275DRE0 J 2-pin connector (CN-B) 1 AB
3- 1C FW-VZB146MRE0 M 12Pin wire harness (CN-C) 1 AG
C1 RC-KZA087DRE0 J Capacitor 0.1 uF 50V 1 AA
C2 VCEAB31VW108M J Capacitor 1000 uF 35V 1 AF
C3 RC-KZA087DRE0 J Capacitor 0.1 uF 50V 1 AA
C4-5 VCEAB31VW106M J Capacitor 10 uF 35V 1 AF
D1-4 VHD11ES1///-1 J Diode (11ES1) 4 AB
D5-8 VHD1SS270A/-1 J Diode (1SS270ATA) 4 AA
Q1-2 VS2SB1238//-3 J Transistor (2SB1238) 2 AA
Q3 VSKRC243M//-3 J Transistor (KRC243M) 1 AB
R1 VRD-B12EF242J J Resistor 2.4k ohm 1/4W 1 AA
R2 VRD-B12HF681J J Resistor 680 ohm 1/2W 1 AA
R3 VRD-B12HF511J J Resistor 510 ohm 1/2W 1 AB
R4 VRD-B12EF270J J Resistor 27 ohm 1/4W 1 AA
R5 VRD-B12EF472J J Resistor 4.7k ohm 1/4W 1 AA
R6 VRD-B12EF332J J Resistor 3.3k ohm 1/4W 1 AA
RY1-2 RRLY-B002MRE0 J Relay (DU24D1-1P(M)) 2 AH
RY1-2 RRLY-A113DRE0 J Relay (DU24D1-1P(M)) Interchangeable 2 AG
SP1 RALM-A014DRE0 J Buzzer (PKM22EPT) 1 AG
T1 RTRNPB009MRE0 M Transformer 1 AM
VRS1 RH-VZA032DRE0 J Varistor (10G471K) 1 AE
ZD1 VHEHZ161///-1 J Zener diode (HZ16-1) 1 AA
3- 2 FPNLCB241MRK0 M Control panel frame with key unit [R-420CK] 1 AX
3- 2 FPNLCB242MRK0 M Control panel frame with key unit [R-420CW] 1 AX
3- 2-1 FUNTKB193MRE0 M Key unit [R-420CK] 1 AW
3- 2-1 FUNTKB194MRE0 M Key unit [R-420CW] 1 AQ
3- 2-2 JBTN-B086MRF0 M Open button [R-420CK] 1 AE
3- 2-2 JBTN-B087MRFO M Open button [R-420CW] 1 AE
3-2-3 MSPRTA050WRE0 M Open button spring 1 AA
3- 3 LHLD-B009MRF0 M LCD holder 1 AF
3- 4 PSHEPB023MRE0 M LED sheet 1 AR
3- 5 XEPSD30P10XS0 M Screw; 3mm x 10mm 1 AA
