Sharp R-420EK User Manual

37
R-420EK
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V. "§" MARK: PARTS DELIVERY SECTION.
*
*
∆
*
ELECTRIC PARTS
1- 1 RC-QZB018MRE0 M High voltage capacitor 1 AQ
1- 2 FH-DZB008MRY0 M High voltage rectifier assembly 1 AM
1- 3 QSOCLB006MRE0 M Oven lamp socket 1 AE
1- 4 RLMPTA068WRE0 M Oven lamp 1 AE
1- 5 RMOTEA346WRE0 M Fan motor 1 AR
1- 6 QFSHDB003MRE0 M Fuse holder 1 AD
1- 7 FFS-BA016/KIT M
Monitor switch (V-16G-2C25) and fuse assembly (20A 250V AC) 1AF
1- 8 QSW-MA085WRE0 M
Secondary interlock switch and door sensing switch (V-16G-3C25) 2AE
1- 9 QFS-TA013WRE0 M Magnetron temperature fuse 150
O
C 1AE
1-10 QFS-TA014WRE0 M Cavity temperature fuse 150
O
C 1AF
1-11 RV-MZA255WRE0 M Magnetron 1 BE
1-12 RMOTDA211/KIT M Turntable motor 1 AL
1-13 RTRN-B064MRE0 M Power transformer 1 BD
1-14 FACCDB003MRE0 M Power supply cord 1 AM
1-15 FDTCTA198WRK0 M AH sensor 1 AN
CABINET PARTS
2- 1 GDAI-B057MRP0A M Base plate 1 AR
2- 2 GLEGPB004MRF0 M Foot 4AB
2- 3 GCABUB092MRP0 M Outer case cabinet 1 AW
CONTROL PANEL PARTS
3- 1 DPWBFB098MRU0 M Control unit 1 BL
3- 1A QCNCMA446DRE0 J 2-pin connector (CN-A) 1 AC
3- 1B QCNCMA275DRE0 J 2-pin connector (CN-B) 1 AB
3- 1C FW-VZB146MRE0 M 12Pin wire harness (CN-C) 1 AG
C2 VCEAB31VW108M J Capacitor 1000 uF 35V 1 AF
D1-4 VHD11ES1///-1 J Diode (11ES1) 4 AB
RY1-2 RRLY-B002MRE0 M Relay (DU24D1-1P(M)) 2 AH
RY1-2 RRLY-A113DRE0 M Relay (DU24D1-1P(M)) Interchangeable 2 AG
SP1 RALM-A014DRE0 J Buzzer (PKM22EPT) 1 AG
T1 RTRNPB009MRE0 M Transformer 1 AM
VRS1 RH-VZA032DRE0 J Varistor (10G471K) 1 AE
3- 2 DPWBFC165WRKZ M LSI Unit 1 AX
3- 3 FPNLCB368/KIT M Control panel frame with key unit 1 AX
3- 4 FUNTKB311/KIT M Key unit 1 AW
3- 5 JBTN-B094MRF0 M Open button 1 AE
3- 6 MSPRTA050WRE0 M Open button spring 1 AA
3- 7 LHLD-B009MRF0 M LCD holder 1 AF
3- 8 PSHEPB023MRE0 M LED sheet 1 AR
3- 9 XEPSD30P10XS0 M Screw; 3mm x 10mm 3 AA
OVEN PARTS
4- 1 LBNDKB007MRP0 M H.V. Capacitor band 1 AB
4- 2 LANGTB048MRP0 M Chassis support 1 AE
4- 3 PHOK-B018MRF0 M Latch hook 1 AF
4- 4 MLEVPB016MRF0 M Switch lever 1 AD
4- 5 PDUC-B104MRF0 M Magnetron duct 1 AF
4- 6 NFANPB006MRE0 M Fan blade 1 AC
4- 7 PDUC-B088MRF0 M Fan duct 1 AC
4- 8 ------------ M Oven cavity (Not a replaceable part) 1 --
4- 9 PCOVPB085MRP0 M Waveguide cover 1 AD
4-10 PPACGB014MRF0 M Turntable motor packing 1 AA
4-11 PDUC-B106MRP0 M AH sensor duct 1 AG
4-12 PCUSGB033MRP0 M Cushion 1 AA
