Sharp R-430DK User Manual

45
R-430DK
R-430DW
R-430DQ
R-440DK
R-440DW
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V. "§" MARK: PARTS DELIVERY SECTION.
*
*
*
∆
*
ELECTRIC PARTS
1- 1 RC-QZB018MRE0 M High voltage capacitor 1 AQ
1- 2 FH-DZB008MRY0 M High voltage rectifier assembly 1 AM
1- 3 QSOCLB006MRE0 M Oven lamp socket 1 AE
1- 4 RLMPTA068WRE0 M Oven lamp 1 AE
1- 5 RMOTEA346WRE0 M Fan motor 1 AR
1- 6 QFSHDB003MRE0 M Fuse holder 1 AD
1- 7 FFS-BA016/KIT M Monitor switch (V-16G-2C25) and fuse assembly (20A 250V AC) 1AF
1- 8 QSW-MA085WRE0 M Secondary interlock switch and door sensing switch (V-16G-3C25) 2AE
1- 9 QFS-TA013WRE0 M Magnetron temperature fuse 150
o
C 1AE
1- 10 QFS-TA014WRE0 M Cavity temperature fuse 150
o
C 1AF
1- 11 RV-MZA255WRE0 M Magnetron 1 BE
1- 12 RMOTDA211/KIT M Turntable motor 1 AL
1- 13 RTRN-B064MRE0 M Power transformer 1 BD
1- 14 FACCDB003WRE0 M Power supply cord 1 AM
1- 15 FDTCTA198WRK0 M AH sensor 1 AN
CABINET PARTS
2- 1 GDAI-B057MRP0 M Base plate 1 AR
2- 2 GLEGPB004MRF0 M Foot 4 AB
2- 3 GCABUB092MRP0 M Outer case cabinet [R-430DK & R-440DK] 1 AV
2- 3 GCABUB093MRP0 M Outer case cabinet [R-430DW & R-440DW] 1 AV
2- 3 GCABUB094MRP0 M Outer case cabinet [R-430DQ] 1 AX
CONTROL PANEL PARTS
3- 1 CPWBFB043MRU0 M Control unit [R-430DK/DW/DQ] 1 BM
3- 1 CPWBFB044MRU0 M Control unit [R-440DK/DW] 1 BM
3- 1-1 DPWBFB095MRU0 M Power unit [R-440DK/DW] 1 AY
3- 1A QCNCMA275DRE0 J 2-pin connector (CN-A) 1 AB
3- 1B QCNCMA275DRE0 J 2-pin connector (CN-B) 1 AB
3- 1C FW-VZB146MRE0 J 12P wire harness (CN-C) [R-430DK/DW/DQ] 1 AG
3- 1C FW-VZB260DREZ J 11P wire harness (CN-C) [R-440DK/DW] 1 AG
C1 RC-KZA087DRE0 J Capacitor 0.1 uF 50V 1 AA
C2 VCEAB31VW108M J Capacitor 1000 uF 35V 1 AF
C3 RC-KZA087DRE0 J Capacitor 0.1 uF 50V 1 AA
C4-5 VCEAB31VW106M J Capacitor 10 uF 35V 2 AA
D1 RSRCDA013DRE0 J Diode Bridge (S1NB10)[R-440DK/DW] 1 AB
D1-4 VHD11ES1///-1 J Diode (11ES1) 4 AB
D5-8 VHD1SS270A/-1 J Diode (1SS270ATA) 4 AA
Q1 VS2SB1859//-3 J Transistor (2SD1859R)[R-440DK/DW] 1 AA
Q1-2 VS2SB1238//-3 J Transistor (2SB1238)[R-430DK/DW/DQ] 2 AA
Q3 VSKRC243M//-3 J Transistor (KRC243M) 1 AB
R1 VRD-B12EF242J J Resistor 2.4k ohm 1/4W 1 AA
R2 VRD-B12HF681J J Resistor 680 ohm 1/2W 1 AA
R2-3 VRD-B13AA910J J Resistor 91 ohm 1 W 2 AA
R3 VRD-B12HF511J J Resistor 510 ohm 1/2W 1 AB
R4 VRD-B12EF270J J Resistor 27 ohm 1/4W 1 AA
R5 VRD-B12EF472J J Resistor 4.7k ohm 1/4W 1 AA
R6 VRD-B12EF332J J Resistor 3.3k ohm 1/4W 1 AA
RY1-2 RRLY-A113DRE0 J Relay (DU24D1-1PR(M)) 2 AG
SP1 RALM-A014DRE0 J Buzzer (PKM22EPT) 1 AG
T1 RTRNPB009MRE0 J Transformer [R-430DK/DW/DQ] 1 AM
T1 RTRNPA113DRE0 J Transformer [R-440DK/DW] 1 AM
VRS1 RH-VZA032DRE0 J Varistor (10G471K) 1 AE
ZD1 VHEHZ161///-1 J Zener diode (HZ16-1) 1 AA
3- 1-2 DPWBFC041WRKZ J LSI unit [R-440DK/DW] 1 AB
3- 2 FPNLCB285MRK0 M Control panel frame with key unit [R-430DK] 1 AX
3- 2 FPNLCB286MRK0 M Control panel frame with key unit [R-430DW] 1 AX
3- 2 FPNLCB287MRK0 M Control panel frame with key unit [R-430DQ] 1 AX
3- 2 FPNLCB305MRK0 M Control panel frame with key unit [R-440DK] 1 AX
3- 2 FPNLCB306MRK0 M Control panel frame with key unit [R-440DW] 1 AX
3- 2- 1 FUNTKB230MRE0 M Key unit [R-430DK] 1 AW
3- 2- 1 FUNTKB231MRE0 M Key unit [R-430DW] 1 AW
3- 2- 1 FUNTKB232MRE0 M Key unit [R-430DQ] 1 AW
3- 2- 1 FUNTKB250MRE0 M Key unit [R-440DK] 1 AW
3- 2- 1 FUNTKB251MRE0 M Key unit [R-440DW] 1 AW
