Sharp R-4A56 User Manual

33
R-4A56
PARTS LIST
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
*
*
*
*
∆
∆
∆
ELECTRICAL PARTS
1- 1 QFS-TA014WRE0 Temp. fuse 150˚C (MG) 1 AG
1- 2 FPWBFA221WRK0 Noise filter (for New Zealand) 1 AX
1- 3 QSW-MA111WRE0 Monitor switch (V-16G-2C25(R)) 1 AK
1- 4 QSW-MA110WRE0 Upper latch switch (V-16G-3C25(R)) 1 AK
1- 5 RTHM-A075WRE0 Thermal cut-out 145˚C (OVEN) 1 AN
1- 6 QACCAA038WRE0 Power supply cord (for Australia) 1 AX
1- 6 QACCAA039WRE0 Power supply cord (for New Zealand) 1 AX
1- 7 FH-DZA063WRK0 H.V. rectifier assembly 1 AX
1- 8 RC-QZA075WRE0 High Voltage capacitor 1 AU
1- 9 QSOCLA011WRE0 Oven lamp socket 1 AH
1-10 RLMPTA029WRE0 Oven lamp 1 AL
1-11 QFS-CA010WRE0 Fuse M8A 1 AE
1-12 RMOTEA303WRE0 Fan motor 1 AX
1-13 RTRN-A430WRE0 Power transformer 1 BQ
1-14 RV-MZA089WRE0 Magnetron 1 BF
1-15 RMOTDA133WRE0 Turntable motor 1 BE
1-16 RR-WZA003WRE0 Monitor resistor 0.8 ohm 20W 1 AG
1-17 QSW-MA110WRE0 Lower latch switch (V-16G-3C25(R)) 1 AK
1-18 QSW-MA110WRE0 Stop switch (V-16G-3C25(R)) 1 AK
1-19 QFSHDA002WRE0 Fuse holder 1 AF
CABINET PARTS
2- 1 FHNG-A172WRT0 Lower oven hinge 1 AM
2- 2 GCABUA415WRP0 Outer case cabinet (until Serial No. 9409xxxxx) 1 BE
2- 2 GCABUA310WRP0 Outer case cabinet (until Serial No. 9410xxxxx) 1 BF
2- 3 MHNG-A280WRT0 Upper oven hinge 1 AM
2- 4 PCOVPA249WRP0 Turntable motor cover 1 AK
2- 5 PCAPHA015WRE0 Cabinet cap 2 AD
2- 6 GLEGPA023WRE0 Foot 4 AC
CONTROL PANEL PARTS
3- 1 CPWBFA498WRK0 Control unit (New zealand only) 1 BF
3- 1A QCNCMA234DRE0 3-pin connector(A) 1 AC
3- 1B QCNCMA275DRE0 2-pin connector(B) 1 AB
3- 1C QCNCWA030DRE0 12-pin connector(G) 1 AF
3- 1D RV-KXA037DRE0 Fluorescent display tube 1 AU
C1 RC-KZA087DRE0 Capacitor 0.1µF 50V 1 AB
C2 VCEAB31VW477M Capacitor 470µF 35V 1 AC
C3 VCEAB31HW335M Capacitor 3.3µF 50V 1 AA
C4 VCEAB31CW476M Capacitor 47µF 16V 1 AA
C5 VCEAB31CW106M Capacitor 10µF 16V 1 AA
C6-7 VCKYD11CY103N Capacitor 0.01µF 16V 2 AH
C10 VCTYF31HF103Z Capacitor 0.01µF 50V 1 AB
C11 VCKYD11CY103N Capacitor 0.01µF 16V 1 AH
C12 VCTYF31HF103Z Capacitor 0.01µF 50V 1 AB
C30 VCEAB31HW104M Capacitor 0.1µF 50V 1 AM
C31 VCEAB31VW475M Capacitor 4.7µF 35V 1 AA
C40 VCKYD11CY103N Capacitor 0.01µF 16V 1 AH
C80 RMPTEA009DRE0 Capacitor array B5RCO122-33N (330pF x 4) 1 AE
CF100 RCRS-A012DRE0 Ceramic resonator (CST4.00MGW) 1 AD
D1-4 VHD11ES1///-1 Diode (11ES1) 4 AB
D20 VHD1SS270A/-1 Diode (1SS270A) 1 AA
D31-32 VHD1SS270A/-1 Diode (1SS270A) 2 AA
D40-41 VHD1SS270A/-1 Diode (1SS270A) 2 AA
D60-67 VHD1SS270A/-1 Diode (1SS270A) 8 AA
IC1 RH-IZA430DRE0 LSI 1 AR
Q1 VSDTC143ES/-3 Transistor (DTC143ES) 1 AB
Q10 VSDTA143ES/-3 Transistor (DTA143ES) 1 AB
Q30 VSDTA114ES/-3 Transistor (DTA114ES) 1 AB
Q31-32 VSDTD143ES/-3 Transistor (DTD143ES) 2 AC
R1 VRD-B12HF432J Resistor 4.3k ohm 1/2W 1 AH
R2 VRD-B12HF102J Resistor 1.0k ohm 1/2W 1 AA
R3 VRD-B12HF122J Resistor 1.2k ohm 1/2W 1 AA
R4 VRD-B12EF471J Resistor 470 ohm 1/4W 1 AA
R5 VRD-B12EF153J Resistor 15k ohm 1/4W 1 AA
R10 VRD-B12EF153J Resistor 15k ohm 1/4W 1 AA
R20 VRD-B12EF102J Resistor 1.0k ohm 1/4W 1 AA
R21 VRD-B12EF332J Resistor 3.3k ohm 1/4W 1 AA
R30 VRD-B12EF153J Resistor 15k ohm 1/4W 1 AA
