Sharp R-744 User Manual

GB-4
EN
OVEN AND ACCESSORIES
11
4
2
3
5
7
8
9
12
13
10
6
11
ACCESSORIES:
Check to make sure that the following
accessories are provided:
14. Turntable
15. Turntable support
16. Coupling
17. Grill rack
Place the turntable support in the cen-
tre of the oven floor so that it can free-
ly rotate around the coupling. Then
place the turntable onto the turntable
support so that it locates firmly into
the coupling.
To avoid turntable damage, ensure
dishes and containers are lifted clear
of the turntable rim when removing
them from the oven.
For use of rack, refer to the sections on
grilling feature on page GB-19.
NOTE: When you order accessories,
please mention two items: part name
and model name to your dealer or
SHARP authorised service agent.
NOTES:
• The waveguide cover is fragile. Care should be taken when cleaning inside the oven to
ensure that it is not damaged.
• Always operate the oven with the turntable and turntable support fitted correctly. This
promotes thorough, even cooking. A badly fitted turntable may rattle, may not rotate
properly and could cause damage to the oven.
• All food and containers of food are always placed on the turntable for cooking.
• Please use grill rack only for grill, it it not recommended for microwave.
OVEN
1. Door handle
2. Oven lamp
3. Door hinges
4. Door safety latches
5. Door
6. Door seals and sealing surfaces
7. Turntable motor shaft
8. Oven cavity
9. Control panel
10. Waveguide cover (DO NOT REMOVE)
11. Grill heating element
12. Power supply cord
13. Outer cabinet
14. Turntable
(glass)
16. Coupling
15. Turntable
support
17
R-744_OM_WEST.indb 4 2017-09-20 11:55:33
