Sharp R-763IN Service Manual

36
R-763 -
ELECTRIC PARTS
* C RC-QZA252WRE0 U High voltage capacitor 1 AP
FM RMOTEA361WRE0 U Fan motor 1 AT
F2 QFS-B0019MRE0 U Fuse 15A 1 AC
F1 QFS-CA025WRE0 U F8A Fuse 1 AC
GH FHET-A040WRK1 U Grill heating element assembly 1 BB
* MG RV-MZA264WRE0 U Magnetron 1 BK
OL RLMPTA066WRE0 U Oven lamp 1 AK
SW1 QSW-MA131WRE0 U Monitored latch switch 1 AK
SW2 QSW-MA133WRE0 U Monitor switch 1 AN
SW3 QSW-MA131WRE0 U Stop switch 1 AK
* T RTRN-A016URE1 U Power transformer 1 BE
TC1 RTHM-A098WRE0 U Thermal cut-out 125°C (Magnetron) 1 AH
TC2 RTHM-A100WRE0 U Thermal cut-out 160°C (Oven) 1 AH
TTM RMOTDA227WRE0 U Turntable motor assy 1 AU
* 1-1 FH-DZA035WRE0 U H.V. rectifier assembly 1 AP
1-2 FPWBFA309WRE2 U Noise filter 1 AT
1-3 QACCVA004URE2 U Power supply cord 1 AQ
PARTS LIST
∆
∆
*
*
*
*
CABINET PARTS
2-1 GCABUA024URP0 U Outer case cabinet (IN) 1 AX
2-2 GLEGPA028WRE0 U Foot 4AA
2-3 GDAI-A219WRP5 U Base Plate 1 AS
3- 1 DPWBFA125URK0 U Control unit 1 BN
3- 1A QCNCMA430DRE0 U 3-pin connector (CN-A) 1 AC
3- 1B QCNCMA414DRE0 U 2-pin connector (CN-B) 1 AB
3- 1C QW-QZA003URE2 U Lead wire (WH-1, WH-2) 2 AB
3- 1D RLCDSA036DRE0 U Liquid crystal display 1 AP
3- 1E LHLD-A002URF1 U LCD holder 1 AC
3- 1F PSHEPA569WRE0 U LED sheet 1 AC
3- 1G QCNCMA151DREZ U 6-pin connector (CN-G) 1 AB
C1 RC-KZA087DRE0 U Capacitor 0.1 uF 50V 1 AB
C2 RC-EZA323DRE0 U Capacitor 470 uF 50V 1 AA
C3 RC-KZA087DRE0 U Capacitor 0.1 uF 50V 1 AB
C4-5 VCKYD41CY103N U Capacitor 0.01 uF 16V 2 AA
C6 RC-EZA322DRE0 U Capacitor 10 uF 50V 1 AB
C7 RC-KZA087DRE0 U Capacitor 0.1 uF 50V 1 AB
C20 RC-EZA322DRE0 U Capacitor 10 uF 50V 1 AB
C21 RC-EZA302DRE0 U Capacitor 0.1 uF 50V 1 AB
C30 VCKYD41CY103N U Capacitor 0.01 uF 16V 1 AA
C50-51 VCKYD41CY103N U Capacitor 0.01 uF 16V 2 AA
CR60 RMPTEA011DRE0 U Capacitor array 1 AG
CF1 RCRS-A012DRE0 U Ceramic resonator 1 AD
D1-4 VHD11ES1///-1 U Diode (11ES1) 4 AB
D20-23 VHD1SS270A/-1 U Diode (1SS270ATA) 4 AA
D30 VHD1SS270A/-1 U Diode (1SS270ATA) 1 AA
IC1 RH-IXA022DRZZ J LSI 1AV
LD1-4 VHPSLZ781C9-3 U Light emitting diode 4 AC
Q1 VSKRA101M//-3 U Transistor (KRA101M) 1 AA
Q2 VSDTA123ES/-3 U Transistor (DTA123ES) 1 AB
Q3 VS2SB1238//-3 U Transistor (2SB1238) 1 AD
Q20 VS2SB1238//-3 U Transistor (2SB1238) 1 AD
Q21-22 VSKRA223M//-3 U Transistor (KRA223M) 2 AB
Q23 VSKRC243M//-3 U Transistor (KRC243M) 1 AB
Q24 VSKRA101M//-3 U Transistor (KRA101M) 1 AA
Q40 VSKRA101M//-3 U Transistor (KRA101M) 1 AA
R1-2 VRS-B13AA511J U Resistor 510 ohm 1W 2 AB
R3-4 VRD-B12EF472J U Resistor 4.7k ohm 1/4W 2 AA
R5 VRD-B12EF241J U Resistor 240 ohm 1/4W 1 AA
R10 VRD-B12EF472J U Resistor 4.7k ohm 1/4W 1 AA
R20 VRD-B12EF102J U Resistor 1.0k ohm 1/4W 1 AA
CONTROL PANEL PARTS
∆
∆
REF. NO. PART NO. § DESCRIPTION Q’TY CODE
Note: The parts marked “*” are used in voltage more than 250V. The parts marked "∆" may cause undue microwave exposure
“§” MARK: SPARE PARTS-DELIVERY SECTION
