Sharp R-7N76(B)M User Manual

R-7N76(W)M
R-7N76(B)M
41
PARTS LIST
Note: The parts marked "∆" may cause undue microwave exposure. / The parts marked "*" are used in
voltage more than 250V. / "§" Mark: Spare parts delivery section
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
*
*
*
*
∆
∆
CONTROL PANEL PARTS
3- 1 CPWBFA633WRK0 J Control unit 1 BR
3- 1A QCNCMA227DRE0 J 5-pin connector (A) 1 AC
3- 1B QCNCMA237DRE0 J 3-pin connector (F) 1 AD
3- 1C QCNCMA267DRE0 J 6-pin connector (C) 1 AC
3- 1D QCNCMA346DRE0 J 6-pin connector (H) 1 AG
3- 1E QCNCWA057DRE0 J 12-pin connector (G) 1 AF
3- 1F RV-KXA062DRE0 J Fluorescent display tube 1 BA
C1 RC-KZA087DRE0 J Capacitor 0.1 uF 50V 1 AB
C2 RC-EZA238DRE0 J Capacitor 1000 uF 35V 1 AD
C3 RC-EZA301DRE0 J Capacitor 47 uF 25V 1 AB
C4 RC-KZA087DRE0 J Capacitor 0.1 uF 50V 1 AB
C5 RC-EZA301DRE0 J Capacitor 47 uF 25V 1 AB
C6-7 VCKYD11CY103N J Capacitor 0.01 uF 16V 2 AH
C8 RC-KZA087DRE0 J Capacitor 0.1 uF 50V 1 AB
C10 RC-KZA087DRE0 J Capacitor 0.1 uF 50V 1 AB
C11 VCKYD11CY103N J Capacitor 0.01 uF 16V 1 AH
C20 RC-EZA322DRE0 J Capacitor 10 uF 35V 1 AC
C21 RC-EZA302DRE0 J Capacitor 0.1 uF 50V 1 AM
C30 VCKYD11CY103N J Capacitor 0.01 uF 16V 1 AH
C50 RC-EZA301DRE0 J Capacitor 47 uF 25V 1 AB
C51 VCKYD11CY103N J Capacitor 0.01 uF 16V 1 AH
C60 VCKYD11CY103N J Capacitor 0.01 uF 16V 1 AH
C70 RMPTEA009DRE0 J CR array (330pF x 4) 1 AE
C80 VCKYD11CY103N J Capacitor 0.01 uF 16V 1 AH
C90 RC-EZA301DRE0 J Capacitor 47 uF 25V 1 AB
C91 VCKYD11CY103N J Capacitor 0.01 uF 16V 1 AH
CF1 RCRS-A012DRE0 J Ceramic resonator (CST4.00MGW) 1 AD
D1 RSRCDA013DRE0 J Diode (S1NB10) 1 AG
ELECTRIC PARTS
1- 1 FH-HZA007WRE0 U Thermistor 1 AH
1- 2 RTRN-A402WRE0 J TC transformer 1 AW
1- 3 QACCBA033WRE1 U Power supply cord assembly 1 AT
1- 4 FH-DZA035WRE0 U High voltage rectifier assembly 1 AP
1- 5 FPWBFA242WRE0 U Noise filter 1 AW
1- 6 RC-QZA075WRE0 U High voltage capacitor 1 AX
1- 7 QSOCLA011WRE0 J Oven lamp socket 1 AH
1- 8 RHET-A120WRE1 U Convection heating element 1 AX
1- 9 RMOTEA289WRE0 U Convection motor 1 AW
1-10 QFS-CA009WRE0 J Fuse 13A 1 AD
1-11 QFS-CA010WRE0 J Fuse M8A 1 AE
1-12 RMOTEA279WRE0 U Fan motor 1 AT
1-13 FHET-A048WRK0 U Grill heating element assembly 1 BB
1-14 RV-MZA177WRE0 U Magnetron 1 BG
1-15 RLMPTA058WRE0 U Oven lamp 1 AG
1-16 RR-WZA003WRE0 J Monitor resistor 0.8Ω 1AG
1-17 QSW-MA110WRE0 J 1st latch switch 1 AK
1-18 QSW-MA110WRE0 J 2nd latch switch 1 AK
1-19 QSW-MA110WRE0 J Stop switch 1 AK
1-20 QSW-MA111WRE0 U Monitor switch 1 AK
1-21 QSW-MA110WRE0 J Damper switch 1 AK
1-22 RTRN-A418WRE0 U High voltage transformer 1 BP
1-23 RTHM-A084WRE0 U Thermal cut-out 170˚C (OVEN) 1 AL
1-24 RTHM-A078WRE0 U Thermal cut-out 125˚C (MG) 1 AL
1-25 RTHM-A004WRE0 U Thermal cut out 190˚C (CONV.) 1 AL
1-26 RMOTDA183WRE0 U Damper motor 1 AV
1-27 FMOTDA057WRK0 J Turntable motor assembly 1 AR
1-28 FDTCTA150WRK0 J AH Sensor 1 AX
CABINET PARTS
2- 1 GCABDA064WRP0 U Back plate 1 AP
2- 2 GCABDA065WRP0 U Sub back plate 1 AH
2- 3 GCABUA445WRP0 U Outer case cabinet (Brown) 1 AX
2- 3 GCABUA469WRT0 U Outer case cabinet (White) 1 AX
2- 4 MHNG-A325WRM0 U Lower oven hinge 1 AC
2- 5 GDAI-A219WRP3 U Base plate 1 AS
2- 6 GLEGPA028WRE0 U Foot 4 AA
