Sharp R-930CS Service Manual

41
R-930CS
PARTS LIST
ELECTRICAL PARTS
1- 1 FACCDA075WRE0 Power supply cord 1 AN
1- 1 FACCDA048WRE0 Power supply cord (Interchangeable) 1 AT
1- 2 FFS-BA012WRK0
Monitor fuse 20A and monitor switch (V-5220D-070) assembly 1AH
1- 3 QFSHDA009WRE0 Fuse holder 1 AF
1- 4 QSW-MA131WRE0 Secondary interlock switch & door sensing switch 2 AG
1- 4 QSW-MA110WRE0
Secondary interlock switch & door sensing switch (Interchangeable) 2AK
1- 5 FH-HZA041WRE0 Thermistor 1 AN
1- 6 QSW-MA110WRE0 Damper aswitch 1 AK
1- 7 QFS-TA013WRE0 Magnetron temperature fuse 150˚C 1 AG
1- 8 RTHM-A085WRE0 Oven thermal cut-out 150˚C 1 AL
1- 9 RMOTDA192WRE0 Damper motor 1 AS
1-10 RLMPTA071WRE0 Oven lamp 1 AK
1-11 QSOCLA021WRE0 Oven lamp socket 1 AG
1-13 RMOTEA283WRE0 Convection fan motor 1 AZ
1-14 RMOTEA300WRE0 Fan motor 1 AZ
1-15 RHET-A136WRE0 Heating element 1 AW
1-16 RTRN-A535WRE0 Power transformer 1 BL
1-16 RTRN-A527WRE0 Power transformer (Interchangeable) 1 BP
1-17 RC-QZA173WRE0 H.V.capacitor 1 AX
1-17 RC-QZA211WRE0 H.V.capacitor (Interchangeable) 1 AV
1-18 FH-DZA053WRK0 H.V.rectifier assembly 1 AP
1-19 RV-MZA256WRE0 Magnetron 1 BL
1-20 RMOTDA222WRE0 Turntable motor 1 AY
1-21 FDTCTA183WRK0 AH sensor assembly 1 AY
CABINET PARTS
2- 1 GCABUA728WRP0 Outer case cabinet 1 BK
2- 2 TMAPCA763WRR0 Schematic diagram 1 AC
2- 3 FDAI-A198WRY0 Base cabinet 1 AM
2- 3-1 GCOVHA156WRP0 Turntable motor cover 1 AB
2- 3-2 XHTSD40P08RV0 Screw; 4mm x 8mm 1 AA
2- 4 GLEGPA019WRE0 Foot 4 AD
2- 5 GCABDA095WRW0 Rear cabinet 1 AH
2- 6 LHLDKA009WRF0 Cord holder 1 AG
2- 7 LBNDKA036WRP0 Capacitor holder 1 AG
2- 8 FHNG-A092WRM0 Oven hinge (Lower) 1 AF
2- 9 PHOK-A112WRF0 Latch hook 1 AM
2-10 MLEVPA231WRF0 Switch lever 1 AE
CONTROL PANEL PARTS
3- 1 CPWBFA748WRK0 Control unit 1 BU
3- 1A QCNCMA227DRE0 5-pin connector(A) 1 AC
3- 1B QCNCMA267DRE0 6-pin connector(E) 1 AC
3- 1C QCNCMA237DRE0 3-pin connector(F) 1 AD
3- 1D QCNCWA057DRE0 12-pin connector(G) 1 AF
3- 1E RV-KXA077DRE0 Fluorescent display tube 1 AY
3- 1F PCUSGA381WRP0 Cushion 2 AG
C1 RC-KZA087DRE0 Capacitor 0.1µF 50V 1 AA
C2 VCEAB31VW108M Capacitor 1000µF 35V 1 AF
C3 RC-KZA087DRE0 Capacitor 0.1µF 50V 1 AA
C4 VCEAB31VW106M Capacitor 10µF 35V 1 AA
C5 RC-KZA087DRE0 Capacitor 0.1µF 50V 1 AA
C6 VCEAB31VW106M Capacitor 10µF 35V 1 AA
C7-8 VCKYD11CY103N Capacitor 0.01µF 16V 2 AA
C9 VCTYF31HF103Z Capacitor 0.01µF 50V 1 AB
C10 RC-KZA087DRE0 Capacitor 0.1µF 50V 1 AA
C11 VCEAB31EW226M Capacitor 22µF 25V 1 AA
C20 VCEAB31VW106M Capacitor 10µF 35V 1 AA
C21 VCEAB31HW104M Capacitor 0.1µF 50V 1 AM
C22 RC-KZA087DRE0 Capacitor 0.1µF 50V 1 AA
C30 VCKYD11CY103N Capacitor 0.01µF 16V 1 AA
C50 VCKYD11CY103N Capacitor 0.01µF 16V 1 AA
C60 VCKYD11CY103N Capacitor 0.01µF 16V 1 AA
C70 RMPTEA009DRE0 Capacitor array 330pF x 4 1 AE
CF1 RCRS-A035DRE0 Ceramic resonator (CST4.19MGW) 1 AG
D1-4 VHD11ES1///-1 Diode (11ES1) 4 AB
D7 VHD1SS270A/-1 Diode (1SS270ATA) 1 AA
*
*
*
*
*
∆
*
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
∆
∆
