R-9H56
38
PARTS LIST
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
*
*
*
*
∆
∆
∆
ELECTRICAL PARTS
1- 1 FH-DZA058WRK0 High voltage rectifier assembly 1 AL
1- 2 FH-HZA041WRE0 Thermistor assembly 1 AN
1- 3 QACCAA040WRE0 Power supply cord 1 AV
1- 4 QFS-CA010WRE0 Fuse (M8A) 1 AE
1- 5 QFS-TA013WRE0 Temperature fuse 150˚C 1 AG
1- 6 QFSHDA002WRE0 Fuse holder 1 AE
1- 7 QSOCLA011WRE0 Oven lamp socket 1 AH
1- 8 QSW-MA111WRE0 Monitor switch 1 AK
1- 9 QSW-MA110WRE0 Stop switch and Damper switch 2 AK
1-10 QSW-MA110WRE0 Upper and lower latch switches 2 AK
1-11 RC-QZA075WRE0 High voltage capacitor 1 AU
1-12 RHET-A139WRE0 Convection heater 1 AY
1-13 RLMPTA029WRE0 Oven lamp 1 AK
1-14 RMOTDA191WRE0 Damper motor 1 AS
1-15 RMOTDA097WRE0 Turntable motor 1 AV
1-16 RMOTEA303WRE0 Cooling fan motor 1 AX
1-17 RMOTEA284WRE0 Convection motor 1 AZ
1-18 RR-WZA003WRE0 Monitor resistor 0.8Ω 20W 1 AG
1-19 RTHM-A085WRE0 Thermal cut-out 150˚C (OVEN) 1 AL
1-20 RTHM-A079WRE0 Thermal cut-out 95˚C (FM) 1 AL
1-21 RTRN-A318WRE0 Power transformer 1 BP
1-22 RV-MZA114WRE0 Magnetron 1 BG
1-23 FDTCTA157WRK0 AH sensor assembly 1 AY
CABINET PARTS
2- 1 FDAI-A181WRY0 Base plate assembly 1 AR
2- 2 FHNG-A092WRM0 Oven hinge (Lower) 1 AF
2- 3 GCABDA074WRW0 Rear cabinet 1 AG
2- 4 GCABUA463WRP0 Outer case cabinet 1 BF
2- 5 GCOVHA156WRP0 Turntable motor cover 1 AB
2- 6 GFTARA001WRW0 Oven lamp access cover 1 AC
2- 7 GLEGPA019WRE0 Foot 4 AD
2- 8 LBNDKA036WRP0 Capacitor holder 1 AG
2- 9 LBSHC0032WRE0 Cord bushing 1 AB
2-10 LSTPPA141WRF0 Cord anchorage (Upper) 1 AD
2-11 LSTPP0009YBF0 Cord anchorage (Lower) 1 AC
2-12 MLEVPA122WRF0 Latch lever 1 AD
2-13 PHOK-A043WRF0 Latch hook 1 AM
CONTROL PANEL PARTS
3- 1 CPWBFA599WRK0 Control unit (Not Replaceble Item) 1 BN
3- 1A QCNCMA227DRE0 5-pin connector(A) 1 AC
3- 1B QCNCMA267DRE0 6-pin connector(E) 1 AC
3- 1C QCNCMA237DRE0 3-pin connector(F) 1 AD
3- 1D QCNCWA030DRE0 12-pin connector(G) 1 AF
3- 1E RV-KXA054DRE0 Fluorescent display tube 1 AW
C1 RC-KZA087DRE0 Capacitor 0.1µF 50V 1 AB
C2 VCEAB31VW108M Capacitor 1000µF 35V 1 AF
C3 VCEAB31HW335M Capacitor 3.3µF 50V 1 AA
C4 VCKYB11EX153N Capacitor 0.015µF 25V 1 AA
C5 VCEAB31CW476M Capacitor 47µF 16V 1 AA
C6 RC-KZA087DRE0 Capacitor 0.1µF 50V 1 AB
C7 VCKYD11CY103N Capacitor 0.01µF 16V 1 AH
C8 RC-KZA087DRE0 Capacitor 0.1µF 50V 1 AB
C10 VCEAB31EW226M Capacitor 22µF 25V 1 AA
C11 RC-KZA087DRE0 Capacitor 0.1µF 50V 1 AB
C20 VCKYD11CY103N Capacitor 0.01µF 16V 1 AH
C21 VCTYF31HF103Z Capacitor 0.01µF 50V 1 AB
C60-61 VCKYD11CY103N Capacitor 0.01µF 16V 2 AH
C70 VCKYD11CY103N Capacitor 0.01µF 16V 1 AH
C80 VCEAB31HW104M Capacitor 0.1µF 50V 1 AM
C81 VCEAB31VW475M Capacitor 4.7µF 35V 1 AA
C100 RMPTEA009DRE0 Capacitor array 330pF x 4 1 AE
CF1 RCRS-A012DRE0 Ceramic resonator (CST4.00MGW) 1 AD
D1-4 VHD11ES1///-1 Diode (11ES1) 4 AB
D7 VHD1SS270A/-1 Diode (1SS270ATA) 1 AA
D70-71 VHD1SS270A/-1 Diode (1SS270ATA) 2 AA
D80-86 VHD1SS270A/-1 Diode (1SS270ATA) 7 AA
D91-98 VHD1SS270A/-1 Diode (1SS270ATA) 8 AA
