6. DESCRIPTION OF PARTS VM-5S
-25-
6-3 DESCRIPTION OF LCD DISPLAY
NO. NAME NO. NAME
1 CH1 measured value (digital) 6 CH2 measured value (digital)
2 CH1 measured value (bar graph) 7 CH2 measured value (bar graph)
3 CH1 sensor set gap voltage value
(VK , FK , RD input specification)
8 CH2 sensor set gap voltage value
(VK , FK , RD input specification)
4 SPEED RELAY 2 set value 9 SPEED RELAY 4 set value
5 SPEED RELAY 1 set value 10 SPEED RELAY 3 set value
LCD display
MEAS2
MEAS1
4
8
12
16
MEAS1 MEAS2
00
20 20
40 40
60 60
80 80
100
%
100
%
%
%
1
4
5
3
2
7
8
10
9
6
20
V
