Private Communication Systems
Mobile Phones
Service Manual C25 / C2588 V 1.0 ICP CD ST
R. Fleuren
Sm_C25_lvl2_v10_w97 Page 9 of 32 02/99
4.2 Necessary tools
For disassembling the C25 the following Case Opener is
mandatory:
Ordering number of Case Opener: F30032-P46-A1
4.3 Disassembling the C25
Attention: ESD regulations have to be followed!
1. You first remove the battery lid and then the battery
below.
2. Now you remove the SIM card.
3. Then you pull the antenna out.
4. Open the housing with the opening tool and carefully
pull the lower housing section off.
