InstallationPXL Conventional Fire Alarm Control Panel
29
TABLE 6
NON-POWER LIMITED WIRING
Module Termination
Enclosure
Knockout
PPS-10M
PRM-4
TB1 (3 positions)
TB6 (All 9 positions)
TB1 (6 positions)
TB2 (6 positions)
7
4
4
4
WIRING IN ENCLOSURE
Non-Power Limited Wiring
The following wiring is considered non-power limited:
from the PTX-12 transformer to PPS-10M, TB1
from the batteries to PPS-10M, TB2 (wiring routed behind trans-
former)
from PPS-10M, NAC power (TB2) to optional PNC-2Z, TB1
To maintain the required separation, the wires must be routed and
held in place by a separate tie-down to lances located on the rear of
the enclosure. See Figure 20 for the location of the lances.
WIRING ENTERING ENCLOSURE
Power Limited Wiring
Wiring to the following PXL module terminations is considered power
limited and must enter the enclosure through the knockouts specified
in Table 7 (Refer to Figure 20). Wiring between the knockout speci-
fied and the module termination must be in the shortest route and
must not overlap any other wiring.
TABLE 7
POWER LIMITED WIRING
Module Termination
Enclosure
Knockout
PCM-1
PNC-2Z
PPS-10M
PZE-4B
All Zone Wiring
TB2 (All positions)
TB3 (All positions)
TB3 (2 positions)
TB4 (All 16 positions)
TB5 (1-4)
All Zone Wiring
1 and 2
3
3
6
6
6
1 and 2
