Appendix BPXL Conventional Fire Alarm Control Panel
65
APPENDIX B
Module Power Calculations
and
Electrical Requirements for
Battery Calculations
MODULE POWER CALCULATIONS
Module Type
+24 VDC
Regulated Current
PCM-1 Module
0.093A
0.093A
PZE-4B Module(s)
Number of modules
________ x 0.031A =
______A
PNC-2Z Module(s)
Number of modules
________ x 0.036A =
______A
PRM-4 Module(s)
Number of modules
________ x 0.060A
______A
LED-3/4 Module(s)
Number of modules
________ x 0.042A
______A
RSA Module(s)
RSA-16R / RSA-16B = 220ma
RSA-16RTL / RSA-16BTL = 450mA
RSA-16RSC / RSA-16BSC = 450mA
Number of modules
________ x ________A =
______A
4 IDC Zones in Alarm
0.720A
0.720A
Total Current
(Must be 1.8A or less per PPS-10M power supply)
______A
