PXL Conventional Fire Alarm Control Panel
Appendix B
66
ELECTRICAL REQUIREMENTS FOR BATTERY CALCULATIONS
Standby
Current
Alarm
Current
PCM-1 Module 0.147A 0.147A
PPS-10M Module 0.088A 0.118A
PZE-4B Module(s) Standby Current 0.039A
Alarm Current 0.039A
Number of modules x current
________ x 0.039A =
______A ______A
PNC-2Z Module(s) Standby Current 0.012A
Alarm Current 0.012A
Number of modules x current
________ x 0.012A =
______A ______A
PRM-4 Module(s) Standby Current 0.007A
Alarm Current 0.067A
Number of modules x current
________ x 0.007A (Standby) =
________ x 0.067A (Alarm) =
______A ______A
IDC Current:
Alarm Current = .180/zone
4 x .180 = 0.72A
0A 0.72A
NAC/Aux Port Current: Current <=2.0A per NAC
Aux ________ <=1.0A Aux
NAC 1 ________ (Max 10A)
NAC 2 ________
NAC 3 ________
NAC 4 ________
NAC 5 ________
NAC 6 ________
NAC 7 ________
NAC 8 ________
NAC 9 ________
NAC 10 ________
NAC 11 ________
NAC 12 ________
NAC 13 ________
NAC 14 ________
NAC 15 ________
NAC 16 ________
0A
0A
0A
0A
0A
0A
0A
0A
0A
0A
0A
0A
0A
0A
0A
0A
0A
______A
______A
______A
______A
______A
______A
______A
______A
______A
______A
______A
______A
______A
______A
______A
______A
______A
LED-3/4 Module(s)
Number of modules
________ x 0.009A (Standby) =
________ x 0.042A (Alarm) =
______A ______A
RSA Module(s)
Number of modules
________ x 0.02A (Standby) =
________ x 0.02A + 0.013 per LED (Alarm) =
______A ______A
Total ______A ______A
Total Standby Current Standby Hours (24, 48, or 60) Standby A-H Current
___________ x __________________ = ______________A-H
Total Alarm Current A-H Multiplier Factor (5 Min.) Alarm A-H Current
___________ x 0.084 = ______________A-H
Total A-H
Total A-H x Batterycharging Factor
_________ x 1.35 = Minimum A-H Battery Size
______________A-H
_________________
<= means less than or equal to
NOTES:
1. A PXL System
reporting to a
Central Station
requires 24 hour
battery back up.
2. A PXL System
reporting as a
Remote Station
system requires 60
hour battery back up.
