24/25
Buildin
g Technolog
ies
CC1N7101en
HVAC Product
s
27.11.2008
Dimensions
Dimensions in mm
5,2
53,9
88
91
41,6
47,2
62,5
7101m02/
0605
22
9
59,1
53,9
7130m05/0904
7,44
L
Type reference
Length «L» in mm
AGK20.20 19
AGK20.43 43
AGK20.55 55
LME...
LME... with extension of
lockout reset button
A
GK20...
Plug-in base AGK11... / AGK13...
23
25
