2 3ZX1012-0RX00-1AA1
AS-Interface
Power Supply Unit 3A, 5A, 8A
3RX9501-0BA00
3RX9502-0BA00
3RX9503-0BA00
Operating Instructions
English
.
The 30 V / 3 A, 5 A, 8 A power supplies with ground-fault detection and
integrated data decoupling are used for operating AS-Interface systems. The
units produce a stabilized 30 V DC voltage with high consistency and low
residual ripple. The output voltage is floating and resistant to short-circuits and
no-load operation. The unit restarts automatically after short-circuits or
overloads. The LED diagnosis is latching and can be deleted using the RESET
function. AS-i + or AS-i – ground faults are detected and only the switched
output ’AS-i + SWITCHED’ will be switched off. The ground fault and overload
displays can be reset by pressing the RESET pushbutton or by means of the HI
signal level at the remote reset input (terminal 41 / 42).
The power supply works according to the principle of a primary switched-mode
regulator and can be connected to a 1-phase AC network with 120 V or 230 V,
50 / 60 Hz or a 2-phase AC network with 120 V or 230 V – 500 V at 8 A.
Please observe the relevant DIN / VDE regulations or country-specific
provisions for device installation.
The device must be mounted vertically for proper cooling. There should be a
space of at least 50 mm above and below the device.
The supply voltage (120 / 230 V AC) must be connected according to VDE 0100
and VDE 0160 (Fig. III).The network must be fused with a maximum of 20 A
(USA) or 16 A (IEC). An internal fuse is available in the device on the primary
side.
The device is mounted by snapping it on to a 35 mm standard mounting rail
(Fig. I).
All end terminals can be removed.
Elemente on the device:
Fig. I: a voltage changeover switch, factory setting 230 V.
Fig. II: b Network connection via terminals,
c AS-Interface connection via terminals,
d Remote reset,
e Ground fault detection,
f Overload LED, red,
g Ground fault detection LED (EFD), yellow,
h Status o.k. LED, green, output voltage
≥ 26,5 V
i RESET pushbutton.
Dimension drawings (dimensions in mm), (Fig. IV).
If not stated otherwise, the data is valid for an input voltage of 230 V AC and an
ambient temperature of +25 °C.
Note
Use copper wires only, rated min. 65/75 °C.
DANGER
Hazardous voltage. Will cause death or serious injury.
Turn off and lock out all power supplying this device before
working on this device. Installation and maintenance work on this
device as well as decommissioning may only be carried out by an
authorized electrician.
Notes
Warning
When using electrical devices, some of their parts are inevitably
energized. For this reason, incorrect use might lead to death or
serious injuries as well as to considerable property damage. Only
qualified personnel is authorized to carry out work on the device
or in its vicinity. Appropriate transport, professional storage, set-
up and mounting are important to ensure proper and safe
functioning of the device.
Electrostatic sensitive devices (ESD). Only qualified personnel is
authorized to open the device.
Death, serious injuries or considerable property damage
might be the consequence if the warnings are not observed!
Application
Mounting / Assembly / Connection
Technical Data
Type 30 V / 3 A 30 V / 5 A 30 V / 8 A
Order number 3RX9501 3RX9502 3RX9503
Input data
Primary voltage AC U
e
120 / 230 V 120 /
230...500 V
Voltage range AC 85...132 /
176...253 V
85...132 /
176...550 V
Mains buffering at I
a Nom
>20ms
Network frequency range 47...63 Hz
Primary rated current 1.6 / 0.9 A 2.7 / 1.5 A 4.4 / 2.4 A
Output data
Voltage (nominal value) U
a Nom 30
30 V DC acc. to AS-i specifications
Residual ripple < 50 mV
pp
(10...500 kHz)
< 300 mV
pp
(0...10 kHz)
Current (nominal value) I
a Nom
3A 5A 8A
Derating (55...70 °C) 2 A 3 A 5 A
Efficiency
at rated output typ. 84 % 87 %
Protection and monitoring
Output overvoltage protection yes (< 35 V)
Current limitation typ. 3.5 A 5.5 A 8.5 A
Safety
Galvanic isolation primary / secondary Output voltage ES1 acc. to
EN 62368-1
Safety class I
Degree of protection IP20
Approvals
CE marking Acc. to 2014/35/EU and 2014/30/EU
UL UL 508
CSA CSA 22.2 107-1
Degree of pollution EN 62368-1
Overvoltage category II up to 2000 m (EN 62368-1)
Galvanic isolation IEC 61588-2-16
EMC
Emitted interference (Class B) EN 61000-6-3
Immunity EN 61000-6-2
Operating data
Ambient temperature Operation
Storage
-10 °C...+70 °C
-25 °C...+80 °C
Degree of pollution 2
Humidity class Climate class according to
DIN 50010, relative humidity max.
100 %, without condensation
