Siemens PXC....D PXC...-E.D + PXA40-… – Automation stations modular series CM1N9222en_03
Building Technologies 16 Mar 2010
Dimensions
Automation stations, system controllers PXC….D
74
192
199
43
4.5
96
93
90
35.5
45
44
66
704
9222m14
81 (PXA40-...)
(PXA40-...)
Option modules PXA40-...
143
9222m15
40
15
All dimensions in mm
