Introduction
1.3Required Tools and Materials
9
Power Supply Terminal Block
Figure1.1 RUGGEDCOM RS900
POWER LED Illuminates green during boot up and when power is supplied to the
device.
ALARM LED Illuminates red when an alarm condition exists.
Console Port The serial console port is for interfacing directly with the device
and accessing initial management functions. For information
about connecting to the device via the serial console port, refer to
"Connecting to the Device (Page 17)".
RESET Button Shuts down and restarts the device. For more information, refer to
"Resetting the Device (Page 18)".
Communication Ports Communication ports in general receive and transmit data, as
well as provide access to the RUGGEDCOM ROS Web interface.
For more information about the various ports available, refer to
"Communication Ports (Page 19)".
Failsafe Alarm Relay Latches to default state when a power disruption or other alarm
condition occurs. For more information, refer to:
• "Connecting the Failsafe Alarm Relay (Page 10)"
• "Failsafe Alarm Relay Specifications (Page 24)"
Power Supply Terminal Blocks Pluggable terminal blocks for connecting one or more power
sources. For more information, refer to "Connecting Power (Page
11)" and "Power Supply Specifications (Page 23)".
1.3 Required Tools and Materials
The following tools and materials are required to install the RUGGEDCOM RS900:
Tools/Materials Purpose
AC power cord (16 AWG) For connecting power to the device.
Multi-mode and/or single-mode fiber optic cables For connecting the device to a LAN.
CAT-5 Ethernet cables For connecting the device to a LAN.
Flathead screwdriver For mounting the device to a DIN rail.
Phillips screwdriver For mounting the device to a panel.
4 x #6-32 screws For mounting the device to a panel.
1.4 Decommissioning and Disposal
Proper decommissioning and disposal of this device is important to prevent malicious
users from obtaining proprietary information and to protect the environment.
Decommissioning
This device may include sensitive, proprietary data. Before taking the device out of
service, either permanently or for maintenance by a third-party, make sure it has
been fully decommissioned.
RUGGEDCOM RS900
Installation Manual, 12/2020, C79000-G8976-1024-12
3
