Siemens SED2-4/32B User Manual

16/126
Siemens Building Technologies SED2 variable speed drives CM1U5192en
HVAC Products Mechanical installation 01.2002
3.3.2 Dimensions of SED2 drives with IP54/NEMA 12 rating
3.3.2.1 Dimensions of SED2 frame sizes B and C
Dimensions in mm
Frame size
ABC
B
385 270 268
C
606
350
284
B
C
A
5
1
9
2
J
0
6
3.3.2.2 Dimensions of SED2 frame sizes D to F
Dimensions in mm
Frame size
ABC
D
685 360 353
E
885 360 453
F
1150 450 473
A
B
C
5
1
9
2
J
0
7
